RACO Saddle Connector: Steel, 2 1/2 in Trade Size - Straight Connectors - Saddle Style
RACOStraight Connectors - Saddle Style

RACO Saddle Connector: Steel, 2 1/2 in Trade Size

The RACO 3310DB is a steel straight saddle-style connector with a 2 1/2 in trade size, designed for use with flexible metal conduit. It features an insulated design and meets UL 514B standards. This connector…

SKU 3G-OTH-05568

Brand
RACO
Item
Saddle Connector: Steel, 2 1/2 in Trade Size
Category
Straight Connectors - Saddle Style
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

RACO
Manufacturer Part Number
3310DB
Material
Steel
Insulated
Yes
Standards
UL 514B
For Use With
Flexible Metal Conduit
Connection Type
Saddle
Connector Style
Straight
Insulated - Broad
Insulated
Connection Orientation
Straight
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

RACO Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The RACO 3310DB is a steel straight saddle-style connector with a 2 1/2 in trade size, designed for use with flexible metal conduit. It features an insulated design and meets UL 514B standards. This connector provides a straight connection orientation for secure conduit terminations.

Frequently Asked Questions

What is the RACO 3310DB saddle connector used for?

The RACO 3310DB is a steel straight saddle-style connector used to terminate flexible metal conduit in industrial electrical installations. Its insulated design provides protection against abrasion and short circuits, making it suitable for panel boxes, junction boxes, and equipment connections in manufacturing and process facilities.

What are the specifications of the RACO 3310DB saddle connector?

The RACO 3310DB is a steel saddle connector with a 2 1/2 in trade size, insulated for added safety. It provides a straight connection orientation for flexible metal conduit and complies with UL 514B standards. The manufacturer part number is 3310DB.

Where to buy the RACO 3310DB saddle connector worldwide?

3G Electric supplies the RACO 3310DB saddle connector to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this steel insulated connector for flexible metal conduit.

How to install a RACO saddle connector on flexible metal conduit?

To install the RACO 3310DB saddle connector, insert the flexible metal conduit into the connector body until it seats fully, then tighten the saddle screw(s) to clamp the conduit securely. Ensure the insulated throat is properly aligned to prevent wire damage. Follow standard electrical practices and torque specifications for safe termination.
