RACO Electrical Box: Steel, 2 Gangs, 3 1/2 in Box Dp, 3 3/4 in Box Wd - Masonry Electrical Boxes
RACOMasonry Electrical Boxes

RACO Electrical Box: Steel, 2 Gangs, 3 1/2 in Box Dp, 3 3/4 in Box Wd

The RACO Electrical Box: Steel is a masonry electrical box designed for industrial installations. This 2-gang box has a depth of 3 1/2 inches, a width of 3 3/4 inches, and a height of 3 3/4 inches. It is supplied…

SKU 3G-OTH-07778

Brand
RACO
Item
Electrical Box: Steel, 2 Gangs, 3 1/2 in Box Dp, 3 3/4 in Box Wd
Category
Masonry Electrical Boxes
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

RACO
Manufacturer Part Number
696
Gangs
2
Box Dp
3 1/2 in
Box Ht
3 3/4 in
Box Wd
3 3/4 in
Clamp Style
Without Clamps
Bracket Style
Without Bracket
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

RACO Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The RACO Electrical Box: Steel is a masonry electrical box designed for industrial installations. This 2-gang box has a depth of 3 1/2 inches, a width of 3 3/4 inches, and a height of 3 3/4 inches. It is supplied without clamps and without a bracket, as specified by manufacturer part number 696.

Frequently Asked Questions

What is the RACO 696 electrical box used for?

The RACO 696 is a steel masonry electrical box used for industrial installations where wiring devices must be embedded in concrete or block walls. Its 2-gang design accommodates multiple switches or receptacles in a single enclosure, providing secure, code-compliant support in poured or block masonry construction.

What are the specifications of the RACO 696 electrical box?

The RACO 696 is a steel masonry box with 2 gangs, a depth of 3 1/2 in, width of 3 3/4 in, and height of 3 3/4 in. It is supplied without clamps and without a bracket. The manufacturer part number is 696, and the brand is RACO.

Where to buy the RACO 696 electrical box worldwide?

3G Electric supplies the RACO 696 electrical box worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time; we source and deliver this RACO masonry box to any international destination.

How to install a RACO masonry electrical box without clamps or bracket?

Install the RACO 696 by securing it to rebar or formwork before pouring concrete, using tie wire or masonry nails through the box's integral mounting holes. Since it has no clamps or bracket, ensure the box is positioned flush with the finished wall surface and properly supported to prevent movement during the pour.
