RACO Liquid-Tight Conduit Fitting: Steel/Iron, 1 1/2 in Trade Size, Insulated - Hazardous Location Liquid-Tight Conduit Fittings
RACOHazardous Location Liquid-Tight Conduit Fittings

RACO Liquid-Tight Conduit Fitting: Steel/Iron, 1 1/2 in Trade Size, Insulated

The RACO 3516-3 is a hazardous location liquid-tight conduit fitting made of iron with a gray finish. It has a 1-1/2 in trade size, a straight connection orientation, and a 1-1/2 in MNPT box connection. This…

SKU 3G-OTH-05469

Brand
RACO
Item
Liquid-Tight Conduit Fitting: Steel/Iron, 1 1/2 in Trade Size, Insulated
Category
Hazardous Location Liquid-Tight Conduit Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

RACO
Manufacturer Part Number
3516-3
Type
Insulated, Indoor/Outdoor
Material
Iron
Color
Gray
Elbow
90°
UNSPSC
39121420
Insulated
Yes
Standards
CSA C22.2 No. 18 Certified
Trade Size
1-1/2 in
For Use With
Flexible Liquid Tight Metallic Conduit
Overall Width
2-13/32 in
Box Connection
1-1/2 in MNPT
Overall Length
2-3/16 in
Country of Origin
China (subject to change)
Indoor/Outdoor Usage
Indoor/Outdoor
Connection Orientation
Straight
Hazardous Location Rating
Class I, Division 2 Class II, Division 1 and 2 Class III, Division 1 and 2
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

RACO Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The RACO 3516-3 is a hazardous location liquid-tight conduit fitting made of iron with a gray finish. It has a 1-1/2 in trade size, a straight connection orientation, and a 1-1/2 in MNPT box connection. This insulated fitting is CSA C22.2 No. 18 Certified and rated for Class I, Division 2; Class II, Division 1 and 2; and Class III, Division 1 and 2 locations, suitable for indoor/outdoor use with flexible liquid-tight metallic conduit.

Frequently Asked Questions

What is the RACO 3516-3 liquid-tight conduit fitting used for?

The RACO 3516-3 is a hazardous location liquid-tight conduit fitting used to connect and protect flexible metallic conduit in industrial environments. It is rated for Class I, Division 2; Class II, Division 1 and 2; and Class III, Division 1 and 2 locations, making it suitable for indoor/outdoor use in areas with combustible dusts or gases.

What are the specifications of the RACO 3516-3 conduit fitting?

The RACO 3516-3 has a 1-1/2 in trade size, 90° elbow, straight connection orientation, and a 1-1/2 in MNPT box connection. It is made of iron with a gray finish, insulated, and CSA C22.2 No. 18 Certified. Overall length is 2-3/16 in and width is 2-13/32 in. It works with flexible liquid-tight metallic conduit.

Where to buy the RACO 3516-3 conduit fitting worldwide?

3G Electric supplies the RACO 3516-3 liquid-tight conduit fitting worldwide. As a global industrial equipment distributor established in 1990, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time. We source and deliver this fitting to support your hazardous location wiring needs.

How to install the RACO 3516-3 liquid-tight conduit fitting?

To install the RACO 3516-3, first ensure the conduit end is clean and cut square. Screw the fitting's male threads into the box or enclosure hand-tight, then use a wrench for final snugness. Insert the flexible liquid-tight metallic conduit into the fitting and tighten the compression nut. Follow local electrical codes and the manufacturer's instructions for hazardous locations.
