RAYCHEM Crankcase Heater: 240V AC, 28 in Lead Lg, 4 ft Overall Lg, 32 W, 50°F On Temp - Crankcase Heaters
RAYCHEMCrankcase Heaters

RAYCHEM Crankcase Heater: 240V AC, 28 in Lead Lg, 4 ft Overall Lg, 32 W, 50°F On Temp

The RAYCHEM Crankcase Heater (SKU 4MC05, MPN 652255-000) is a 240V AC industrial crankcase heater. It includes 28-inch pre-stripped wire leads and has a 4-foot overall length, 32W power rating, and a 50°F on temperature.

SKU 3G-OTH-59689

Brand
RAYCHEM
Item
Crankcase Heater: 240V AC, 28 in Lead Lg, 4 ft Overall Lg, 32 W, 50°F On Temp
Category
Crankcase Heaters
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

RAYCHEM
Manufacturer Part Number
652255-000
Type
32 W
Overall Lg
4 ft
AC
240V
Lead Lg
28 in
On Temp
50°F
Voltage
240V AC
Includes
28 in Pre-Stripped Wire Leads
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

RAYCHEM Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The RAYCHEM Crankcase Heater (SKU 4MC05, MPN 652255-000) is a 240V AC industrial crankcase heater. It includes 28-inch pre-stripped wire leads and has a 4-foot overall length, 32W power rating, and a 50°F on temperature.

Frequently Asked Questions

What is a RAYCHEM crankcase heater used for?

A RAYCHEM crankcase heater prevents refrigerant migration and oil dilution in compressors by maintaining a 50°F on temperature. It is used in HVAC and refrigeration systems to protect compressor bearings and reduce start-up wear, ensuring reliable operation in industrial cooling applications.

What are the specifications of the RAYCHEM crankcase heater 652255-000?

The RAYCHEM crankcase heater (MPN 652255-000) operates at 240V AC with a 32W power rating. It has a 4 ft overall length, 28 in pre-stripped wire leads, and a 50°F on temperature. This 240V AC heater is designed for industrial compressor applications.

Where to buy a RAYCHEM crankcase heater worldwide?

3G Electric supplies the RAYCHEM crankcase heater (MPN 652255-000) worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for availability and lead time on this 240V AC crankcase heater.

How to install a RAYCHEM crankcase heater?

Install the RAYCHEM crankcase heater by wrapping it around the compressor sump and securing it with the provided 28 in pre-stripped wire leads. Connect to a 240V AC power source. Ensure the heater contacts the crankcase surface evenly for proper heat transfer and 50°F on-temperature activation.

Used in

Common applications for RAYCHEM
Pipe freeze protection — RAYCHEM cut-to-length heating cables (e.g., SKU 2VEV6) for indoor water pipes in commercial buildings
Roof de-icing — RAYCHEM WinterGard heating cables with roof clips (SKU 5JC39) to prevent ice dam formation
Process temperature maintenance — RAYCHEM indoor/outdoor cables (e.g., SKU 4E516) for industrial piping in refineries
Freeze protection control — RAYCHEM AMC-F5 thermostat (SKU 45RK48) for automatic activation of heating cables in outdoor enclosures
Splice and tee connections — RAYCHEM splice and tee kit (SKU 4DC50) for branching heating cable runs in complex installations
Snow melting — RAYCHEM 240V AC cables (e.g., SKU 2VEV9) for outdoor walkways and loading docks

RAYCHEM Products

3G Electric supplies RAYCHEM crankcase heaters. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
