RULAND MANUFACTURINGHigh-Precision Set Screw Beam Shaft Couplings

RULAND MANUFACTURING Motion Control Coupling: 3° Angular Misalignment, 6 mm Bore Dia 1, Aluminum

SKU 3G-OTH-188708

Brand

RULAND MANUFACTURING

Item

Motion Control Coupling: 3° Angular Misalignment, 6 mm Bore Dia 1, Aluminum

Technical Specifications

RULAND MANUFACTURING

Manufacturer Part Number

PSMR19-6-6-A

Type

6 mm Bore Dia 1, Aluminum, 1

View Full Spec Sheet

Technical Documents

No technical documents available for this product.

Request documentation →

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

RULAND MANUFACTURING Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

The RULAND MANUFACTURING Motion Control Coupling (MPN PSMR19-6-6-A) is a high-precision set screw beam shaft coupling designed for 3° angular misalignment. It features a round, aluminum body with metric dimensions and same bore dimensions, accommodating a 6 mm bore diameter. This coupling is not keyed and is suitable for motion control applications requiring accurate shaft alignment.

Frequently Asked Questions

What is the RULAND MANUFACTURING PSMR19-6-6-A motion control coupling used for?

The RULAND MANUFACTURING PSMR19-6-6-A is a high-precision set screw beam shaft coupling used in motion control applications that require accurate shaft alignment. It accommodates up to 3° angular misalignment and is ideal for connecting two 6 mm shafts in automation, robotics, and precision machinery.

What are the specifications of the RULAND MANUFACTURING PSMR19-6-6-A coupling?

The RULAND MANUFACTURING PSMR19-6-6-A coupling has a round aluminum body with metric dimensions and same bore diameters of 6 mm. It is not keyed, handles 3° angular misalignment, and is designed for high-precision motion control. The manufacturer part number is PSMR19-6-6-A.

Where to buy the RULAND MANUFACTURING PSMR19-6-6-A coupling worldwide?

3G Electric supplies the RULAND MANUFACTURING PSMR19-6-6-A coupling to customers worldwide. We handle full logistics, customs clearance, and delivery, ensuring you receive genuine RULAND MANUFACTURING components for your motion control applications. Contact us for availability and lead times.

How to select the correct RULAND MANUFACTURING beam coupling for shaft misalignment?

To select the correct RULAND MANUFACTURING beam coupling, match bore diameters to your shaft sizes (e.g., 6 mm), confirm the coupling can handle your system's angular misalignment (up to 3° for the PSMR19-6-6-A), and choose material (aluminum for low inertia). Ensure the coupling is not keyed if your shafts are keyless.

Used in

Common applications for RULAND MANUFACTURING

Automated packaging machinery — Ruland beam couplings (e.g., PSR20-8-5-A) for connecting servo motors to conveyor drive shafts.

CNC machine tools — Ruland rigid couplings (e.g., CLX-4-4-A) for precise alignment of ball screw assemblies.

Robotic arm joints — Ruland Oldham coupling hubs (e.g., OSC16-6-A) for accommodating axial motion in end-effector drives.

Pump and compressor systems — Ruland stainless steel shaft collars (e.g., CL-3-ST) for securing impeller shafts.

Printing press rollers — Ruland clamp-on beam couplings (e.g., PCR18-8-8-A) for synchronizing roller rotation with minimal backlash.

Material handling conveyors — Ruland set screw couplings (e.g., PSMR29-7-7-A) for linking gearboxes to drive rollers.

RULAND MANUFACTURING Products

3G Electric supplies RULAND MANUFACTURING high-precision set screw beam shaft couplings. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
