RULAND MANUFACTURINGHigh-Precision Clamp-On Beam Shaft Couplings

RULAND MANUFACTURING Motion Control Coupling: 3° Angular Misalignment, 4 mm Bore Dia 1, Clamp On

SKU 3G-OTH-202044

Brand

RULAND MANUFACTURING

Item

Motion Control Coupling: 3° Angular Misalignment, 4 mm Bore Dia 1, Clamp On

Technical Specifications

RULAND MANUFACTURING

Manufacturer Part Number

PCMR16-4-3-SS

Type

4 mm Bore Dia 1, Clamp On, 1

View Full Spec Sheet

Technical Documents

No technical documents available for this product.

Request documentation →

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

RULAND MANUFACTURING Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

The RULAND MANUFACTURING PCMR16-4-3-SS is a high-precision clamp-on beam shaft coupling designed for motion control applications. It accommodates 3° angular misalignment and features a 4 mm bore diameter for one end, with different bore dimensions available for the other end. This metric, round-bodied coupling is supplied with a clamp-on style attachment.

Frequently Asked Questions

What is the RULAND MANUFACTURING PCMR16-4-3-SS coupling used for?

The RULAND MANUFACTURING PCMR16-4-3-SS is a high-precision clamp-on beam shaft coupling used in motion control applications. It connects two shafts while accommodating up to 3° of angular misalignment, making it ideal for precision positioning systems, robotics, and automated machinery where accurate torque transmission is required.

What are the specifications of the RULAND MANUFACTURING PCMR16-4-3-SS?

The PCMR16-4-3-SS is a metric, round-bodied beam coupling with a 4 mm bore diameter on one end and different bore dimensions on the other. It features a clamp-on attachment style, accommodates 3° angular misalignment, and is manufactured by RULAND MANUFACTURING. The part number is PCMR16-4-3-SS.

Where to buy the RULAND MANUFACTURING PCMR16-4-3-SS worldwide?

3G Electric supplies the RULAND MANUFACTURING PCMR16-4-3-SS coupling worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your location. Contact us to source this high-precision motion control coupling for your application.

How to select the correct RULAND MANUFACTURING beam coupling for misalignment?

To select the correct RULAND MANUFACTURING beam coupling, first measure your shaft diameters and required misalignment tolerance. The PCMR16-4-3-SS handles 3° angular misalignment with a 4 mm bore. Ensure the clamp-on style matches your shaft attachment needs. Consult RULAND MANUFACTURING's technical data for torque and speed ratings.

Used in

Common applications for RULAND MANUFACTURING

Automated packaging machinery — Ruland beam couplings (e.g., PSR20-8-5-A) for connecting servo motors to conveyor drive shafts.

CNC machine tools — Ruland rigid couplings (e.g., CLX-4-4-A) for precise alignment of ball screw assemblies.

Robotic arm joints — Ruland Oldham coupling hubs (e.g., OSC16-6-A) for accommodating axial motion in end-effector drives.

Pump and compressor systems — Ruland stainless steel shaft collars (e.g., CL-3-ST) for securing impeller shafts.

Printing press rollers — Ruland clamp-on beam couplings (e.g., PCR18-8-8-A) for synchronizing roller rotation with minimal backlash.

Material handling conveyors — Ruland set screw couplings (e.g., PSMR29-7-7-A) for linking gearboxes to drive rollers.
