RULAND MANUFACTURINGZero-Backlash Curved Jaw Coupling Hubs

RULAND MANUFACTURING Jaw Coupling Hub: JC16 Coupling Size, 1 in Outside Dia, Inch, Aluminum

The RULAND MANUFACTURING JCC16-6-A is a zero-backlash curved jaw coupling hub in the JC16 coupling size, with a 1 in outside diameter. This inch, aluminum, curved-type hub is designed for motion control applications…

SKU 3G-OTH-134115

Brand

RULAND MANUFACTURING

Item

Jaw Coupling Hub: JC16 Coupling Size, 1 in Outside Dia, Inch, Aluminum

Technical Specifications

RULAND MANUFACTURING

Manufacturer Part Number

JCC16-6-A

Type

Inch, Aluminum, Curved

Outside Dia

1 in

View Full Spec Sheet

Technical Documents

No technical documents available for this product.

Request documentation →

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

RULAND MANUFACTURING Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

What is a RULAND MANUFACTURING Jaw Coupling Hub used for?

A RULAND MANUFACTURING Jaw Coupling Hub, such as the JCC16-6-A, is used to connect two shafts in power transmission applications while accommodating minor misalignment. It is commonly found in industrial machinery, pumps, and gearboxes where zero-backlash and vibration damping are required.

What are the specifications of the RULAND MANUFACTURING JCC16-6-A coupling hub?

The RULAND MANUFACTURING JCC16-6-A is a zero-backlash curved jaw coupling hub in the JC16 size. It has a 1 in outside diameter, is made of aluminum, and uses an inch-series design. The manufacturer part number is JCC16-6-A, and it is a curved-jaw type hub.

Where to buy RULAND MANUFACTURING coupling hubs worldwide?

You can source RULAND MANUFACTURING coupling hubs like the JCC16-6-A through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to select the correct RULAND MANUFACTURING jaw coupling hub?

To select the correct RULAND MANUFACTURING jaw coupling hub, match the hub outside diameter and bore size to your shaft dimensions. For the JCC16-6-A, ensure the 1 in outside diameter fits your coupling spider. Always verify torque and misalignment requirements per the manufacturer's guidelines.

Used in

Common applications for RULAND MANUFACTURING

Automated packaging machinery — Ruland beam couplings (e.g., PSR20-8-5-A) for connecting servo motors to conveyor drive shafts.

CNC machine tools — Ruland rigid couplings (e.g., CLX-4-4-A) for precise alignment of ball screw assemblies.

Robotic arm joints — Ruland Oldham coupling hubs (e.g., OSC16-6-A) for accommodating axial motion in end-effector drives.

Pump and compressor systems — Ruland stainless steel shaft collars (e.g., CL-3-ST) for securing impeller shafts.

Printing press rollers — Ruland clamp-on beam couplings (e.g., PCR18-8-8-A) for synchronizing roller rotation with minimal backlash.

Material handling conveyors — Ruland set screw couplings (e.g., PSMR29-7-7-A) for linking gearboxes to drive rollers.
