SANDVIK COROMANT Turning Insert: CNMG 12 04 08-MF 1125 (MPN CNMG 432-MF 1125)

This diamond-shaped indexable turning insert is used for medium to finishing turning operations on steel and cast iron workpieces. It is designed for general machining applications in industries such as automotive, aerospace, and general engineering where reliable chip control and surface finish are required.

The insert has the designation CNMG 12 04 08-MF 1125, also listed as MPN CNMG 432-MF 1125. It is a diamond indexable turning insert with a 80° rhombic shape, 4.76 mm thickness, and 0.8 mm nose radius. The 1125 grade is a CVD-coated carbide for steel machining.

3G Electric supplies SANDVIK COROMANT turning inserts worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for pricing and lead time on the CNMG 12 04 08-MF 1125 insert.

Match the insert size (IC 12.7 mm), thickness (4.76 mm), and nose radius (0.8 mm) to your tool holder's pocket dimensions. The CNMG geometry suits general turning of steel and cast iron. For optimal performance, verify your workpiece material and choose the appropriate grade, such as the 1125 for medium cutting speeds.
