SCHAEFER Exhaust Fan: Belt Drive, 48 in Blade, 1 hp, Totally Enclosed Air Over, 23,391 cfm
The SCHAEFER Exhaust Fan: Belt Drive is a belt-drive slant-wall exhaust fan with a 48-inch blade and a 1 hp motor. It delivers 23,391 cfm and operates on 208 to 230/460V AC, three-phase power. The unit features a…
SKU 3G-OTH-80820
Need installation or engineering help?
Ask a question
Product Description
The SCHAEFER Exhaust Fan: Belt Drive is a belt-drive slant-wall exhaust fan with a 48-inch blade and a 1 hp motor. It delivers 23,391 cfm and operates on 208 to 230/460V AC, three-phase power. The unit features a glossy fiberglass frame and a Totally Enclosed Air Over motor enclosure.
Frequently Asked Questions
What is the SCHAEFER belt-drive slant-wall exhaust fan used for?
This SCHAEFER exhaust fan is designed for high-volume ventilation in industrial and commercial facilities. Its 48-inch blade and 23,391 cfm capacity make it suitable for removing heat, fumes, and airborne contaminants from large spaces like warehouses, factories, and assembly plants.
What are the specifications of the SCHAEFER FFM485G1-3 exhaust fan?
The SCHAEFER FFM485G1-3 is a belt-drive slant-wall exhaust fan with a 48-inch blade, 1 hp motor, and 23,391 cfm airflow. It operates on 208 to 230/460V AC three-phase power, features a Totally Enclosed Air Over motor enclosure, and has a glossy fiberglass frame.
Where to buy the SCHAEFER FFM485G1-3 exhaust fan worldwide?
3G Electric supplies the SCHAEFER FFM485G1-3 exhaust fan to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time on this belt-drive slant-wall fan.
How to install a belt-drive slant-wall exhaust fan?
Installation of a belt-drive slant-wall fan like the SCHAEFER FFM485G1-3 requires mounting the unit securely to a wall opening, ensuring proper belt tension, and connecting to the specified 208 to 230/460V AC three-phase power. Always follow the manufacturer's manual and local electrical codes for safe operation.
Used in
Common applications for SCHAEFERSCHAEFER Products
3G Electric supplies SCHAEFER belt-drive slant-wall exhaust fans. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
