SCHAEFER Agricultural Exhaust Fan: Direct Drive, 16 in Blade, 1/3 hp, Totally Enclosed Air Over - Direct-Drive Cylinder Exhaust Fans
SCHAEFERDirect-Drive Cylinder Exhaust Fans

SCHAEFER Agricultural Exhaust Fan: Direct Drive, 16 in Blade, 1/3 hp, Totally Enclosed Air Over

The SCHAEFER PFM163P13 is a direct-drive cylinder exhaust fan designed for agricultural applications. It features a 16-inch blade, a 1/3 hp motor with a Totally Enclosed Air Over enclosure, and delivers 3,217 cfm…

SKU 3G-OTH-82696

Brand
SCHAEFER
Item
Agricultural Exhaust Fan: Direct Drive, 16 in Blade, 1/3 hp, Totally Enclosed Air Over
Category
Direct-Drive Cylinder Exhaust Fans
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHAEFER
Manufacturer Part Number
PFM163P13
Type
1/3 hp, Totally Enclosed Air Over, 3,217 cfm
Blade
16 in
Frame Finish
Polished
Frame Material
Polyethylene
Motor Enclosure
Totally Enclosed Air Over
Nameplate Voltage
115/230V AC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHAEFER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHAEFER PFM163P13 is a direct-drive cylinder exhaust fan designed for agricultural applications. It features a 16-inch blade, a 1/3 hp motor with a Totally Enclosed Air Over enclosure, and delivers 3,217 cfm. The fan operates on 115/230V AC nameplate voltage and has a polished polyethylene frame.

Frequently Asked Questions

What is the SCHAEFER PFM163P13 exhaust fan used for?

The SCHAEFER PFM163P13 is a direct-drive cylinder exhaust fan designed for agricultural ventilation. It moves 3,217 cfm with a 16-inch blade and a 1/3 hp motor, making it suitable for barns, greenhouses, and livestock facilities where reliable air exchange is critical.

What are the specifications of the SCHAEFER PFM163P13?

The SCHAEFER PFM163P13 has a 16-inch blade, 1/3 hp motor with Totally Enclosed Air Over enclosure, and delivers 3,217 cfm. It operates on 115/230V AC nameplate voltage, features a polished polyethylene frame, and carries manufacturer part number PFM163P13.

Where to buy the SCHAEFER PFM163P13 worldwide?

3G Electric supplies the SCHAEFER PFM163P13 direct-drive exhaust fan to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time on this agricultural ventilation fan.

How to install the SCHAEFER PFM163P13 exhaust fan?

Mount the SCHAEFER PFM163P13 securely in a wall or ceiling opening, ensuring the polyethylene frame is sealed against leaks. Wire the 115/230V AC motor per local codes, and verify the Totally Enclosed Air Over enclosure has free airflow for cooling. Follow the manufacturer's manual for torque and clearance.
