SCHNEIDER Overload Relay: Thermal Protection, 3 Poles, 1NO/1NC - IEC Thermal Overload Relays
SCHNEIDERIEC Thermal Overload Relays

SCHNEIDER Overload Relay: Thermal Protection, 3 Poles, 1NO/1NC

The SCHNEIDER Overload Relay: Thermal Protection (MPN LR3D32L) is a 3-pole IEC thermal overload relay with integrated bimetallic elements, eliminating the need for separate thermal units. It features a 1NO/1NC…

SKU 3G-OTH-41587

Brand
SCHNEIDER
Item
Overload Relay: Thermal Protection, 3 Poles, 1NO/1NC
Category
IEC Thermal Overload Relays
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
LR3D32L
Type
1NO/1NC, TeSys Deca (25 to 38 Amp Models)
Poles
3
Compatible Contactors
TeSys Deca (25 to 38 Amp Models)
Auxiliary Contact Form
1NO/1NC
Maximum Voltage Rating
690V AC
Phase Loss Sensitivity
No
Thermal Units Required
None (Relay Includes Integrated Bimetallic Elements)
Terminal Connection Type
Screw Clamp Terminals
Compatible Contactor Series
TeSys Deca
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER Overload Relay: Thermal Protection (MPN LR3D32L) is a 3-pole IEC thermal overload relay with integrated bimetallic elements, eliminating the need for separate thermal units. It features a 1NO/1NC auxiliary contact form, screw clamp terminals, and a maximum voltage rating of 690V AC. This relay is compatible with TeSys Deca contactors (25 to 38 Amp models) and does not include phase loss sensitivity.

Frequently Asked Questions

What is the SCHNEIDER LR3D32L overload relay used for?

The SCHNEIDER LR3D32L is a 3-pole IEC thermal overload relay that protects motors from overheating by monitoring current and tripping when excessive heat is detected. It is used in industrial motor control applications and integrates directly with TeSys Deca contactors (25 to 38 Amp models) for coordinated protection.

What are the specifications of the SCHNEIDER LR3D32L overload relay?

The SCHNEIDER LR3D32L is a 3-pole thermal overload relay with 1NO/1NC auxiliary contacts, screw clamp terminals, and a maximum voltage rating of 690V AC. It includes integrated bimetallic elements, so no separate thermal units are required. It is compatible with TeSys Deca contactors (25 to 38 Amp models) and does not offer phase loss sensitivity.

Where to buy the SCHNEIDER LR3D32L overload relay worldwide?

3G Electric supplies the SCHNEIDER LR3D32L overload relay to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us for pricing and lead time on this TeSys Deca-compatible thermal overload relay.

How to install the SCHNEIDER LR3D32L overload relay?

To install the SCHNEIDER LR3D32L, mount it directly onto a compatible TeSys Deca contactor (25 to 38 Amp models) using the screw clamp terminals. Ensure the motor full-load current is within the relay's adjustment range. Follow standard IEC wiring practices and verify the auxiliary contacts (1NO/1NC) are correctly connected for your control circuit.
