SCHNEIDER General Purpose Relay: Socket Mounted, 15 A Current Rating, 120V AC, 4PDT - Socket-Mounted Relays
SCHNEIDERSocket-Mounted Relays

SCHNEIDER General Purpose Relay: Socket Mounted, 15 A Current Rating, 120V AC, 4PDT

The SCHNEIDER Harmony™ RPM Series General Purpose Relay is a socket-mounted relay with a square base and flat pins for plug-in mounting. It features a 4PDT contact configuration, a 15 A current rating at 120V AC, and…

SKU 3G-OTH-40707

Brand
SCHNEIDER
Item
General Purpose Relay: Socket Mounted, 15 A Current Rating, 120V AC, 4PDT
Category
Socket-Mounted Relays
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
RPM42F7
Series
Harmony™ RPM Series
Type
4PDT, F Socket
AC
120V
Base Type
Square
Pin Shape
Flat
Current Rating
15 A
Mounting Style
Plug-In
Electrical Connection
Quick-Connect
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER Harmony™ RPM Series General Purpose Relay is a socket-mounted relay with a square base and flat pins for plug-in mounting. It features a 4PDT contact configuration, a 15 A current rating at 120V AC, and quick-connect electrical connections (MPN RPM42F7).
