SCHNEIDER Flush Push Button: Red, 22 mm Mounting Size, Metallic - Flush-Mount & Recessed Push-Button Operators
SCHNEIDERFlush-Mount & Recessed Push-Button Operators

SCHNEIDER Flush Push Button: Red, 22 mm Mounting Size, Metallic

The SCHNEIDER Flush Push Button (MPN ZB4BA434) is a metallic, momentary-action push-button operator from the XB4 series, featuring a red actuator with a 'Stop' legend and a 22 mm mounting size. This flush-mount and…

SKU 3G-OTH-34117

Brand
SCHNEIDER
Item
Flush Push Button: Red, 22 mm Mounting Size, Metallic
Category
Flush-Mount & Recessed Push-Button Operators
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
ZB4BA434
Series
XB4
Action
Momentary
Legend
Stop
Push Button Material Type
Metallic
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER Flush Push Button (MPN ZB4BA434) is a metallic, momentary-action push-button operator from the XB4 series, featuring a red actuator with a 'Stop' legend and a 22 mm mounting size. This flush-mount and recessed push-button operator is designed for industrial control panel applications requiring a momentary contact action.

Frequently Asked Questions

What is the SCHNEIDER ZB4BA434 flush push button used for?

The SCHNEIDER ZB4BA434 is a metallic, momentary-action push-button operator from the XB4 series, used as a stop control in industrial control panels. Its red actuator with 'Stop' legend provides clear emergency-stop or halt functionality in machinery and automation systems.

What are the specifications of the SCHNEIDER ZB4BA434 push button?

The SCHNEIDER ZB4BA434 is a momentary-action flush push button with a 22 mm mounting size, metallic construction, and a red actuator labeled 'Stop'. It is part of the XB4 series and designed for industrial panel applications requiring reliable momentary contact.

Where to buy the SCHNEIDER ZB4BA434 worldwide?

You can source the SCHNEIDER ZB4BA434 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring you receive genuine SCHNEIDER components for your control panel needs.

How to install the SCHNEIDER ZB4BA434 flush push button?

Install the SCHNEIDER ZB4BA434 by mounting it into a 22 mm panel cutout, securing it with the provided nut. Connect wiring to the normally open contact block (sold separately) per your control circuit. Ensure the actuator is flush with the panel surface for proper operation.
