SCHNEIDER Compact Smart Relay: (12) Resistive, (8) Relay - Schneider Zelio Series Smart Relays
SCHNEIDERSchneider Zelio Series Smart Relays

SCHNEIDER Compact Smart Relay: (12) Resistive, (8) Relay

The SCHNEIDER ELECTRIC Compact Smart Relay (SKU 2GNL1) is a Schneider Zelio Series smart relay with 12 resistive inputs and 8 relay outputs. It operates on 24V AC or 24V DC power and does not include a clock. This…

SKU 3G-OTH-28969

Brand
SCHNEIDER
Item
Compact Smart Relay:
Category
Schneider Zelio Series Smart Relays
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
SR2E201BD
Type
(8) Relay, 24V AC : 24V DC
Clock Included
Clock Not Included
Number and Type of Inputs
(12) Resistive
Number and Type of Outputs
(8) Relay
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER ELECTRIC Compact Smart Relay (SKU 2GNL1) is a Schneider Zelio Series smart relay with 12 resistive inputs and 8 relay outputs. It operates on 24V AC or 24V DC power and does not include a clock. This unit is identified by manufacturer part number SR2E201BD.

Frequently Asked Questions

What is the SCHNEIDER ELECTRIC Compact Smart Relay SR2E201BD used for?

The SCHNEIDER ELECTRIC Compact Smart Relay SR2E201BD is used for industrial automation and control applications. It manages logic sequences, timing, and switching in machinery, conveyors, and building systems. With 12 resistive inputs and 8 relay outputs, it suits small to medium control tasks where a programmable logic controller is not required.

What are the specifications of the SCHNEIDER ELECTRIC Compact Smart Relay SR2E201BD?

The SCHNEIDER ELECTRIC Compact Smart Relay SR2E201BD is a Zelio Series unit with 12 resistive inputs and 8 relay outputs. It operates on 24V AC or 24V DC power and does not include a clock. The manufacturer part number is SR2E201BD. It is a compact smart relay for basic logic control.

Where to buy the SCHNEIDER ELECTRIC Compact Smart Relay SR2E201BD worldwide?

You can source the SCHNEIDER ELECTRIC Compact Smart Relay SR2E201BD through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time. 3G Electric supplies genuine Schneider components for industrial automation.

How to install the SCHNEIDER ELECTRIC Compact Smart Relay SR2E201BD?

Mount the SCHNEIDER ELECTRIC Compact Smart Relay SR2E201BD on a DIN rail in a clean, dry enclosure. Connect 24V AC or 24V DC power to the designated terminals. Wire resistive inputs and relay outputs per your control schematic. Follow Schneider Zelio Series installation guidelines for proper wiring and isolation.
