SCHNEIDERWired Rotating Lights

SCHNEIDER Beacon Light: Red, LED, 24V AC/DC, 4 3/4 in Overall Dia, 4 3/4 in Overall Ht

The SCHNEIDER XVR12B04S is a red LED wired rotating beacon light with a threaded mount, operating at 24V AC/DC. It features a 4 3/4 in overall diameter and height, providing visual signaling for industrial applications.

SKU 3G-OTH-559460

Brand

SCHNEIDER

Item

Beacon Light: Red, LED, 24V AC/DC, 4 3/4 in Overall Dia, 4 3/4 in Overall Ht

Technical Specifications

SCHNEIDER

Manufacturer Part Number

XVR12B04S

Type

LED, XVR12B04S

AC/DC

24V

Lens Color

Red

Overall Ht

4 3/4 in

Overall Dia

4 3/4 in

Mounting Location

Threaded Mount

Operating Voltage

24V AC/DC

View Full Spec Sheet

Technical Documents

No technical documents available for this product.

Request documentation →

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

SCHNEIDER Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

What is the SCHNEIDER XVR12B04S beacon light used for?

The SCHNEIDER XVR12B04S is a red LED wired rotating beacon light used for visual signaling in industrial environments. It alerts personnel to machine status, alarms, or process events, making it suitable for manufacturing, material handling, and facility safety applications.

What are the specifications of the SCHNEIDER XVR12B04S?

The SCHNEIDER XVR12B04S is a red LED beacon light operating at 24V AC/DC. It has a 4 3/4 in overall diameter and height, with a threaded mount. The part number is XVR12B04S, and it is designed for wired rotating light applications.

Where to buy the SCHNEIDER XVR12B04S worldwide?

3G Electric supplies the SCHNEIDER XVR12B04S beacon light worldwide. As a global industrial solutions provider, we handle logistics, customs, and delivery to your location. Contact us to source this part for your facility.

How to install the SCHNEIDER XVR12B04S beacon light?

Mount the SCHNEIDER XVR12B04S using its threaded mount on a compatible surface. Connect the 24V AC/DC power supply per the wiring diagram. Ensure the lens is clean and the unit is securely fastened. Follow standard industrial electrical safety practices during installation.
