SCHNEIDER Tower Light Assembly: 3 Tier, Green/Orange/Red, No Sounder Tier - Three-Tier Tower Light Assemblies
SCHNEIDERThree-Tier Tower Light Assemblies

SCHNEIDER Tower Light Assembly: 3 Tier, Green/Orange/Red, No Sounder Tier

The SCHNEIDER Tower Light Assembly: 3 Tier is a three-tier tower light assembly with an orange light tier color. It operates at a voltage of 100 to 240V and is identified by manufacturer part number XVC1M3K.

SKU 3G-OTH-40000

Brand
SCHNEIDER
Item
Tower Light Assembly: 3 Tier, Green/Orange/Red, No Sounder Tier
Category
Three-Tier Tower Light Assemblies
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
XVC1M3K
Type
Green/Orange/Red, No Sounder Tier
Overall Ht
372 mm
Light Tier Color
Orange
Operating Voltage
100 to 240V
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER Tower Light Assembly: 3 Tier is a three-tier tower light assembly with an orange light tier color. It operates at a voltage of 100 to 240V and is identified by manufacturer part number XVC1M3K.

Frequently Asked Questions

What is the SCHNEIDER XVC1M3K tower light used for?

The SCHNEIDER XVC1M3K is a three-tier tower light assembly used for visual status indication on industrial machinery, conveyors, and process equipment. The green, orange, and red tiers signal normal operation, warning, and alarm conditions respectively, helping operators quickly assess machine state.

What are the specifications of the SCHNEIDER XVC1M3K tower light?

The SCHNEIDER XVC1M3K is a 3-tier tower light assembly with green, orange, and red light tiers and no sounder tier. It has an overall height of 372 mm, operates at 100 to 240V, and features an orange light tier color. The manufacturer part number is XVC1M3K.

Where to buy the SCHNEIDER XVC1M3K tower light worldwide?

You can source the SCHNEIDER XVC1M3K tower light worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to install the SCHNEIDER XVC1M3K tower light?

Mount the SCHNEIDER XVC1M3K on a flat surface using the base holes, connect the 100 to 240V supply to the terminal block per the wiring diagram, and secure each tier by twisting it onto the stack. Ensure the voltage matches the rating before powering on.
