SCHNEIDER Magnetic Contactor: Non-Reversing, 3 Poles, 3NO Contacts, 80 A - Non-Reversing IEC Contactors
SCHNEIDERNon-Reversing IEC Contactors

SCHNEIDER Magnetic Contactor: Non-Reversing, 3 Poles, 3NO Contacts, 80 A

The SCHNEIDER IEC Magnetic Contactor: Non-Reversing (SKU 3DB24, MPN LC1D80B7) is a non-reversing IEC contactor with 3 poles and 3NO contacts, rated at 80 A with a 24V AC coil. It does not include integrated surge…

SKU 3G-OTH-45376

Brand
SCHNEIDER
Item
Magnetic Contactor: Non-Reversing, 3 Poles, 3NO Contacts, 80 A
Category
Non-Reversing IEC Contactors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
LC1D80B7
Type
80 A
Poles
3
AC Coil
24V
Contacts
3NO
Integrated Surge Suppression
No
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER IEC Magnetic Contactor: Non-Reversing (SKU 3DB24, MPN LC1D80B7) is a non-reversing IEC contactor with 3 poles and 3NO contacts, rated at 80 A with a 24V AC coil. It does not include integrated surge suppression.

Frequently Asked Questions

What is the SCHNEIDER LC1D80B7 contactor used for?

The SCHNEIDER LC1D80B7 is an IEC magnetic contactor used for switching electrical loads in industrial motor control, lighting, and power distribution applications. Its 80 A rating and 24V AC coil make it suitable for controlling three-phase motors and other equipment in manufacturing and process industries.

What are the specifications of the SCHNEIDER LC1D80B7 contactor?

The SCHNEIDER LC1D80B7 is a non-reversing IEC contactor with 3 poles and 3 normally open (3NO) contacts. It is rated at 80 A with a 24V AC coil and does not include integrated surge suppression. The manufacturer part number is LC1D80B7.

Where to buy the SCHNEIDER LC1D80B7 contactor worldwide?

3G Electric supplies the SCHNEIDER LC1D80B7 contactor worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us for pricing and lead time on this genuine SCHNEIDER part.

How to select the right SCHNEIDER contactor for an 80 A load?

For an 80 A load, select a contactor like the SCHNEIDER LC1D80B7 with a matching current rating and coil voltage (24V AC). Ensure the contact configuration (3NO) suits your circuit. Verify that the contactor's utilization category (e.g., AC-3 for motors) matches your application for reliable switching.

Used in

Common applications for SCHNEIDER
Motor starting in conveyor systems — Schneider Altistart ATS 22 soft starters (e.g., ATS22D17S6U) reduce inrush current.
Speed control for industrial pumps — Schneider Altivar ATV320 VFDs (e.g., ATV320U55N4W) provide variable flow regulation.
Machine safety interlocking — Schneider XPSUAF13AP safety relays monitor emergency stop circuits on assembly lines.
Panel-mounted control stations — Schneider XB5 flush push buttons (ZB5AA5) serve as start/stop operators in MCCs.
Heavy-duty motor switching — Schneider LC1G150LSEA contactors handle 150 A loads in compressor and crusher applications.
Emergency stop actuation — Schneider 9001K mushroom-head push buttons (9001KR25R) provide red, momentary stop functions.
