SCHNEIDER Selector Switch: 30 mm Panel Mounting Size, 3 Positions, Short Lever, 2NO/2NC - Selector Switches
SCHNEIDERSelector Switches

SCHNEIDER Selector Switch: 30 mm Panel Mounting Size, 3 Positions, Short Lever, 2NO/2NC

The SCHNEIDER 9001K Series Selector Switch (SKU 45C542, MPN 9001KS46BH2) is a 30 mm panel-mounting, non-illuminated selector switch with a short-handled knob and metallic bezel. It features a…

SKU 3G-OTH-36638

Brand
SCHNEIDER
Item
Selector Switch: 30 mm Panel Mounting Size, 3 Positions, Short Lever, 2NO/2NC
Category
Selector Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
9001KS46BH2
Series
9001K
Type
Short Lever, 2NO/2NC, Metallic
Cam
F
Action
Maintained/Maintained/Maintained
Positions
3
AC Contact Rating
1.5 A @ 480 V
DC Contact Rating
0.55 A @125 V
Operator Head Type
Short-Handled Knob
Operator Illumination
Non-Illuminated
Operator Head Material
Polycarbonate
Switch Bezel Material Type
Metallic
Switch Function @ 1st Position
On
Switch Function @ 2nd Position
Off
Switch Function @ 3rd Position
On
Switch Function @ 4th Position
No Fourth Position
Hazardous Location Specification
Not Rated
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER 9001K Series Selector Switch (SKU 45C542, MPN 9001KS46BH2) is a 30 mm panel-mounting, non-illuminated selector switch with a short-handled knob and metallic bezel. It features a maintained/maintained/maintained action across three positions (On/Off/On) with a Cam F operator, and is rated for AC contact at 1.5 A @ 480 V and DC contact at 0.55 A @ 125 V. The operator head is made of polycarbonate, and the switch is not rated for hazardous locations.

Frequently Asked Questions

What is the SCHNEIDER 9001KS46BH2 selector switch used for?

The SCHNEIDER 9001KS46BH2 is a 30 mm panel-mount selector switch used for industrial control circuits, such as machine on/off selection or mode switching. Its maintained three-position action (On/Off/On) suits applications requiring stable state retention, like conveyor systems or motor controls, in non-hazardous environments.

What are the specifications of the SCHNEIDER 9001KS46BH2 selector switch?

The SCHNEIDER 9001KS46BH2 is a 30 mm panel-mount selector switch with a short-handled polycarbonate knob and metallic bezel. It has three maintained positions (On/Off/On) with Cam F action, AC contact rating of 1.5 A @ 480 V, DC contact rating of 0.55 A @ 125 V, and 2NO/2NC contacts. It is non-illuminated and not rated for hazardous locations.

Where to buy the SCHNEIDER 9001KS46BH2 selector switch worldwide?

You can source the SCHNEIDER 9001KS46BH2 selector switch worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we supply genuine SCHNEIDER components for industrial control applications.

How to install the SCHNEIDER 9001KS46BH2 selector switch?

Install the SCHNEIDER 9001KS46BH2 by mounting it in a 30 mm panel cutout and securing with the provided nut. Wire the 2NO/2NC contacts according to your control circuit, ensuring the AC or DC load does not exceed the rated 1.5 A @ 480 V or 0.55 A @ 125 V. Use proper torque on terminals and verify maintained action positions before powering.
