SCHNEIDER Supplementary Protector: 32 A Amps, 60V DC, 14kA at 120/240V AC, Screw Clamp - C-Curve, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors
SCHNEIDERC-Curve, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors

SCHNEIDER Supplementary Protector: 32 A Amps, 60V DC, 14kA at 120/240V AC, Screw Clamp

The SCHNEIDER IEC Supplementary Protector is a C-Curve, 1-Pole UL1077 DIN Rail-Mount Supplementary Protector rated at 32 A Amps. It features a Max. AIR Rating of 14kA at 120/240V AC, AC Voltage Rating of 240/415V AC…

SKU 3G-OTH-19846

Brand
SCHNEIDER
Item
Supplementary Protector: 32 A Amps, 60V DC, 14kA at 120/240V AC, Screw Clamp
Category
C-Curve, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
M9F22132
Series
C60SP
Type
14kA at 120/240V AC, Screw Clamp, C60SP, C
DC
60V
Curve Type
C
Max. AIR Rating
14kA at 120/240V AC
AC Voltage Rating
240/415V AC
DC Voltage Rating
60V DC
Terminal Connection
Screw Clamp
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER IEC Supplementary Protector is a C-Curve, 1-Pole UL1077 DIN Rail-Mount Supplementary Protector rated at 32 A Amps. It features a Max. AIR Rating of 14kA at 120/240V AC, AC Voltage Rating of 240/415V AC, and DC Voltage Rating of 60V DC, with a Screw Clamp terminal connection. This model, part of the C60SP series (MPN M9F22132), provides overcurrent protection for industrial equipment.

Frequently Asked Questions

What is the SCHNEIDER IEC Supplementary Protector used for?

The SCHNEIDER IEC Supplementary Protector provides overcurrent protection for industrial equipment. It is a C-Curve, 1-Pole UL1077 DIN Rail-Mount device rated at 32 A Amps, suitable for protecting control circuits, motor starters, and other sensitive loads in manufacturing and process industries.

What are the specifications of the SCHNEIDER M9F22132?

The SCHNEIDER M9F22132 is a C60SP series supplementary protector with 32 A Amps, 60V DC rating, 14kA at 120/240V AC, and 240/415V AC rating. It features a Screw Clamp terminal connection and a C-Curve trip characteristic. This UL1077 device is designed for DIN rail mounting.

Where to buy SCHNEIDER supplementary protectors worldwide?

3G Electric supplies SCHNEIDER supplementary protectors worldwide. As a global industrial distributor since 1990, we handle full logistics, customs clearance, and delivery to your site. Contact us to source the SCHNEIDER M9F22132 or other C60SP series protectors for your application.

How to install a SCHNEIDER C60SP supplementary protector?

Install the SCHNEIDER C60SP on a standard DIN rail by clipping it into place. Use a screwdriver to tighten the Screw Clamp terminals to the recommended torque. Ensure the circuit is de-energized before installation. Follow generic best practices for overcurrent protection device mounting and wiring.
