SCHNEIDER Supplementary Protector: 40 A Amps, 10kA at 240V AC, Screw Clamp - C-Curve, 3-Pole UL1077 DIN Rail-Mount Supplementary Protectors
SCHNEIDERC-Curve, 3-Pole UL1077 DIN Rail-Mount Supplementary Protectors

SCHNEIDER Supplementary Protector: 40 A Amps, 10kA at 240V AC, Screw Clamp

The SCHNEIDER IEC Supplementary Protector is a C-Curve, 3-Pole UL1077 DIN Rail-Mount Supplementary Protector rated at 40 A Amps. Part of the C60SP series (MPN M9F22340), it features a Max. AIR Rating of 10kA at 240V…

SKU 3G-OTH-19752

Brand
SCHNEIDER
Item
Supplementary Protector: 40 A Amps, 10kA at 240V AC, Screw Clamp
Category
C-Curve, 3-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
M9F22340
Series
C60SP
Type
10kA at 240V AC, Screw Clamp, C60SP
Max. AIR Rating
10kA at 240V AC
AC Voltage Rating
240/415/440V AC
DC Voltage Rating
Not Rated
Terminal Connection
Screw Clamp
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER IEC Supplementary Protector is a C-Curve, 3-Pole UL1077 DIN Rail-Mount Supplementary Protector rated at 40 A Amps. Part of the C60SP series (MPN M9F22340), it features a Max. AIR Rating of 10kA at 240V AC and an AC Voltage Rating of 240/415/440V AC, with a Screw Clamp terminal connection. This device is not rated for DC voltage.

Frequently Asked Questions

What is the SCHNEIDER C60SP supplementary protector used for?

The SCHNEIDER C60SP supplementary protector (MPN M9F22340) is a 40 A, 3-pole, C-curve device used to protect branch circuits and equipment from overcurrent and short circuits in industrial control panels, HVAC systems, and machinery. It is UL1077 listed for DIN-rail mounting and rated 10kA at 240V AC.

What are the specifications of the SCHNEIDER M9F22340?

The SCHNEIDER M9F22340 is a C60SP series supplementary protector rated 40 A, 3-pole, C-curve, with a max AIR rating of 10kA at 240V AC. AC voltage rating is 240/415/440V AC; DC voltage rating is not rated. Terminal connection is screw clamp. It is UL1077 listed for DIN-rail mounting.

Where to buy SCHNEIDER M9F22340 supplementary protector worldwide?

3G Electric supplies the SCHNEIDER M9F22340 C60SP supplementary protector worldwide. As a global industrial sourcing partner, we handle full logistics, customs clearance, and delivery to your facility. Contact us for a quote and lead time on this 40 A, 3-pole, C-curve device.

How to install a SCHNEIDER C60SP DIN-rail supplementary protector?

To install the SCHNEIDER C60SP, snap it onto a standard 35 mm DIN rail. Ensure the circuit is de-energized. Connect phase conductors to the screw-clamp terminals (torque per manufacturer specs). For a 3-pole device, wire all three poles. Verify the C-curve trip characteristic matches your load type.
