SCHNEIDER Supplementary Protector: 16 A Amps, 14kA at 240V AC, Screw Clamp - C-Curve, 4-Pole UL1077 DIN Rail-Mount Supplementary Protectors
SCHNEIDERC-Curve, 4-Pole UL1077 DIN Rail-Mount Supplementary Protectors

SCHNEIDER Supplementary Protector: 16 A Amps, 14kA at 240V AC, Screw Clamp

The SCHNEIDER ELECTRIC IEC Supplementary Protector is a C-Curve, 4-Pole UL1077 DIN Rail-Mount device rated for 16 A Amps. Part of the C60SP series (MPN M9F22416), it features a Max. AIR Rating of 14kA at 240V AC and…

SKU 3G-OTH-20199

Brand
SCHNEIDER
Item
Supplementary Protector: 16 A Amps, 14kA at 240V AC, Screw Clamp
Category
C-Curve, 4-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
M9F22416
Series
C60SP
Type
14kA at 240V AC, Screw Clamp, C
Max. AIR Rating
14kA at 240V AC
DC Voltage Rating
Not Rated
Terminal Connection
Screw Clamp
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER ELECTRIC IEC Supplementary Protector is a C-Curve, 4-Pole UL1077 DIN Rail-Mount device rated for 16 A Amps. Part of the C60SP series (MPN M9F22416), it features a Max. AIR Rating of 14kA at 240V AC and a Screw Clamp terminal connection, with no DC Voltage Rating.

Frequently Asked Questions

What is the SCHNEIDER ELECTRIC IEC Supplementary Protector used for?

This C-Curve, 4-Pole UL1077 DIN Rail-Mount supplementary protector is used to protect branch circuits and equipment from overcurrent and short circuits in industrial control panels, HVAC systems, and machinery. It is rated for 16 A Amps and 14kA at 240V AC, making it suitable for commercial and light industrial applications.

What are the specifications of the SCHNEIDER C60SP M9F22416?

The SCHNEIDER C60SP M9F22416 is a 4-Pole supplementary protector with a C-Curve trip characteristic, rated 16 A Amps. It has a Max. AIR Rating of 14kA at 240V AC, a Screw Clamp terminal connection, and no DC Voltage Rating. It is UL1077 listed and mounts on a DIN rail.

Where to buy SCHNEIDER C60SP supplementary protectors worldwide?

3G Electric supplies the SCHNEIDER C60SP M9F22416 supplementary protector worldwide. As a global industrial equipment distributor established in 1990, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time on this C-Curve, 4-Pole UL1077 device.

How to install a SCHNEIDER C60SP DIN rail supplementary protector?

To install the SCHNEIDER C60SP, snap it onto a standard 35mm DIN rail. Ensure the circuit is de-energized. Connect wires to the Screw Clamp terminals, tightening to the torque specified on the device label. Verify the C-Curve rating matches your load. Always follow local electrical codes and Schneider's installation manual.

Used in

Common applications for SCHNEIDER
Motor starting in conveyor systems — Schneider Altistart ATS 22 soft starters (e.g., ATS22D17S6U) reduce inrush current.
Speed control for industrial pumps — Schneider Altivar ATV320 VFDs (e.g., ATV320U55N4W) provide variable flow regulation.
Machine safety interlocking — Schneider XPSUAF13AP safety relays monitor emergency stop circuits on assembly lines.
Panel-mounted control stations — Schneider XB5 flush push buttons (ZB5AA5) serve as start/stop operators in MCCs.
Heavy-duty motor switching — Schneider LC1G150LSEA contactors handle 150 A loads in compressor and crusher applications.
Emergency stop actuation — Schneider 9001K mushroom-head push buttons (9001KR25R) provide red, momentary stop functions.
