SCHNEIDER Supplementary Protector: 6 A Amps, 500V DC, 5kA at 250V DC, Screw Clamp - DC-Only Rated, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
SCHNEIDERDC-Only Rated, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors

SCHNEIDER Supplementary Protector: 6 A Amps, 500V DC, 5kA at 250V DC, Screw Clamp

The SCHNEIDER IEC Supplementary Protector (SKU 482P21, MPN M9U31206) is a DC-only rated, 2-pole UL1077 DIN rail-mount supplementary protector from the C60H-DC series. It features a 6 A amp rating, a D curve type, a…

SKU 3G-OTH-22440

Brand
SCHNEIDER
Item
Supplementary Protector: 6 A Amps, 500V DC, 5kA at 250V DC, Screw Clamp
Category
DC-Only Rated, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
M9U31206
Series
C60H-DC
Type
5kA at 250V DC, Screw Clamp, C60H-DC, D
DC
500V
Curve Type
D
Max. AIR Rating
5kA at 250V DC
AC Voltage Rating
Not Rated
DC Voltage Rating
500V DC
Terminal Connection
Screw Clamp
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER IEC Supplementary Protector (SKU 482P21, MPN M9U31206) is a DC-only rated, 2-pole UL1077 DIN rail-mount supplementary protector from the C60H-DC series. It features a 6 A amp rating, a D curve type, a DC voltage rating of 500V DC, and a maximum AIR rating of 5kA at 250V DC. The unit uses screw clamp terminals and is not rated for AC voltage.

Frequently Asked Questions

What is the SCHNEIDER C60H-DC supplementary protector used for?

The SCHNEIDER C60H-DC supplementary protector (MPN M9U31206) is used for DC circuit protection in industrial control panels, solar arrays, and battery systems. It is a 2-pole, UL1077-listed device rated for 6 A at 500V DC, with a D curve for high inrush loads. It mounts on a DIN rail and uses screw clamp terminals.

What are the specifications of the SCHNEIDER M9U31206 supplementary protector?

The SCHNEIDER M9U31206 is a 6 A, 2-pole supplementary protector from the C60H-DC series. It has a DC voltage rating of 500V DC, a maximum AIR rating of 5kA at 250V DC, and a D curve type. It uses screw clamp terminals and is not rated for AC voltage. It is UL1077 listed for DIN rail mounting.

Where to buy SCHNEIDER C60H-DC supplementary protectors worldwide?

You can source the SCHNEIDER C60H-DC supplementary protector (MPN M9U31206) through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead times.

How to install a SCHNEIDER C60H-DC supplementary protector?

To install the SCHNEIDER C60H-DC supplementary protector, mount it onto a standard DIN rail and secure it with the integrated clip. Connect DC supply wires to the screw clamp terminals, ensuring proper torque per the manufacturer's instructions. Verify polarity and that the system is de-energized before installation. Always follow local electrical codes.
