SCHNEIDER Magnetic Contactor: Non-Reversing, 3 Poles, 3NO Contacts, 9 A - Non-Reversing IEC Contactors
SCHNEIDERNon-Reversing IEC Contactors

SCHNEIDER Magnetic Contactor: Non-Reversing, 3 Poles, 3NO Contacts, 9 A

The SCHNEIDER IEC Magnetic Contactor: Non-Reversing (SKU 482Z21, MPN LC1D09EHE) is a non-reversing IEC contactor with 3 poles and 3NO contacts rated at 9 A. It features a nominal coil voltage of 48V AC at 60Hz and…

SKU 3G-OTH-52926

Brand
SCHNEIDER
Item
Magnetic Contactor: Non-Reversing, 3 Poles, 3NO Contacts, 9 A
Category
Non-Reversing IEC Contactors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
LC1D09EHE
Type
9 A
Poles
3
Contacts
3NO
AC/48V AC Coil
120V
Nominal Coil Voltage @ 60Hz
48V AC
Integrated Surge Suppression
No
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER IEC Magnetic Contactor: Non-Reversing (SKU 482Z21, MPN LC1D09EHE) is a non-reversing IEC contactor with 3 poles and 3NO contacts rated at 9 A. It features a nominal coil voltage of 48V AC at 60Hz and does not include integrated surge suppression.

Frequently Asked Questions

What is the SCHNEIDER IEC Magnetic Contactor LC1D09EHE used for?

The SCHNEIDER IEC Magnetic Contactor LC1D09EHE is used for switching electrical loads in industrial motor control and automation applications. It is suitable for non-reversing motor starters, lighting control, and power distribution systems where reliable on/off control of 3-phase circuits is required.

What are the specifications of the SCHNEIDER LC1D09EHE contactor?

The SCHNEIDER LC1D09EHE is a non-reversing IEC contactor with 3 poles and 3NO contacts rated at 9 A. It has a nominal coil voltage of 48V AC at 60Hz and does not include integrated surge suppression. The coil also accepts 120V AC input. The manufacturer part number is LC1D09EHE.

Where to buy the SCHNEIDER LC1D09EHE contactor worldwide?

You can source the SCHNEIDER LC1D09EHE contactor worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we supply genuine SCHNEIDER components for industrial applications.

How to select the right SCHNEIDER contactor for my application?

To select the right SCHNEIDER contactor, match the coil voltage (e.g., 48V AC for the LC1D09EHE) to your control circuit, ensure the current rating (9 A) exceeds your load, and verify pole count (3 poles for 3-phase). Consider whether surge suppression is needed. Consult a SCHNEIDER catalog or contact 3G Electric for guidance.

Used in

Common applications for SCHNEIDER
Motor starting in conveyor systems — Schneider Altistart ATS 22 soft starters (e.g., ATS22D17S6U) reduce inrush current.
Speed control for industrial pumps — Schneider Altivar ATV320 VFDs (e.g., ATV320U55N4W) provide variable flow regulation.
Machine safety interlocking — Schneider XPSUAF13AP safety relays monitor emergency stop circuits on assembly lines.
Panel-mounted control stations — Schneider XB5 flush push buttons (ZB5AA5) serve as start/stop operators in MCCs.
Heavy-duty motor switching — Schneider LC1G150LSEA contactors handle 150 A loads in compressor and crusher applications.
Emergency stop actuation — Schneider 9001K mushroom-head push buttons (9001KR25R) provide red, momentary stop functions.
