SCHNEIDER Pilot Light Head: 22 mm Panel Mounting Hole Dia, Green, Fresnel, LED - Pilot-Light Heads
SCHNEIDERPilot-Light Heads

SCHNEIDER Pilot Light Head: 22 mm Panel Mounting Hole Dia, Green, Fresnel, LED

The SCHNEIDER ELECTRIC Pilot Light Head is a 22 mm panel-mounting pilot-light head from the XB5 series. It features a green Fresnel lens and is compatible with a Universal LED Module. This component is designed for…

SKU 3G-OTH-30627

Brand
SCHNEIDER
Item
Pilot Light Head: 22 mm Panel Mounting Hole Dia, Green, Fresnel, LED
Category
Pilot-Light Heads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
ZB5AV033S
Type
Green, Fresnel, LED, XB5 Series
Compatible with Series
XB5
Compatible Lamp Module Type
Universal LED Module
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER ELECTRIC Pilot Light Head is a 22 mm panel-mounting pilot-light head from the XB5 series. It features a green Fresnel lens and is compatible with a Universal LED Module. This component is designed for use with the XB5 series and carries the manufacturer part number ZB5AV033S.
