SCHNEIDER Overload Relay: Thermal Protection, 3 Poles, 1NO/1NC - IEC Thermal Overload Relays
SCHNEIDERIEC Thermal Overload Relays

SCHNEIDER Overload Relay: Thermal Protection, 3 Poles, 1NO/1NC

The SCHNEIDER IEC Overload Relay: Thermal Protection (MPN LR3D14) is a three-pole thermal overload relay with integrated bimetallic elements, requiring no external thermal units. It features a 1NO/1NC auxiliary…

SKU 3G-OTH-41069

Brand
SCHNEIDER
Item
Overload Relay: Thermal Protection, 3 Poles, 1NO/1NC
Category
IEC Thermal Overload Relays
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
LR3D14
Type
1NO/1NC, TeSys Deca (9 to 38 Amp Models)
Poles
3
Compatible Contactors
TeSys Deca (9 to 38 Amp Models)
Auxiliary Contact Form
1NO/1NC
Maximum Voltage Rating
690V AC
Phase Loss Sensitivity
No
Thermal Units Required
None (Relay Includes Integrated Bimetallic Elements)
Terminal Connection Type
Screw Clamp Terminals
Compatible Contactor Series
TeSys Deca
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER IEC Overload Relay: Thermal Protection (MPN LR3D14) is a three-pole thermal overload relay with integrated bimetallic elements, requiring no external thermal units. It features a 1NO/1NC auxiliary contact configuration, screw clamp terminals, and a maximum voltage rating of 690V AC. This relay is compatible with TeSys Deca contactors in the 9 to 38 Amp models and does not include phase loss sensitivity.

Frequently Asked Questions

What is the SCHNEIDER LR3D14 overload relay used for?

The SCHNEIDER LR3D14 is a three-pole thermal overload relay used to protect motors from overcurrent and phase imbalance. It integrates bimetallic elements and is designed for use with TeSys Deca contactors in industrial automation and HVAC applications.

What are the specifications of the SCHNEIDER LR3D14 overload relay?

The SCHNEIDER LR3D14 is a three-pole thermal overload relay with a 1NO/1NC auxiliary contact form, screw clamp terminals, and a maximum voltage rating of 690V AC. It includes integrated bimetallic elements, requires no external thermal units, and is compatible with TeSys Deca contactors (9 to 38 Amp models).

Where to buy the SCHNEIDER LR3D14 overload relay worldwide?

You can source the SCHNEIDER LR3D14 overload relay through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring reliable supply for your operations.

How to select the correct SCHNEIDER overload relay for a motor?

Select the SCHNEIDER overload relay based on the motor's full-load current rating and the contactor series. The LR3D14 is designed for TeSys Deca contactors in the 9 to 38 Amp range. Ensure the relay's current setting matches the motor nameplate and that auxiliary contacts meet control circuit requirements.
