SCHNEIDER Push Button Head: 22 mm Panel Size, Non-Illuminated, O - Heads for Push Buttons
SCHNEIDERHeads for Push Buttons

SCHNEIDER Push Button Head: 22 mm Panel Size, Non-Illuminated, O

The SCHNEIDER ELECTRIC Push Button Head (MPN ZBA7432) is a non-illuminated head for push buttons with a 22 mm panel size and a red color. It features a snap-on head attachment type and is compatible with the ZB4…

SKU 3G-OTH-32176

Brand
SCHNEIDER
Item
Push Button Head: 22 mm Panel Size, Non-Illuminated, O
Category
Heads for Push Buttons
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
ZBA7432
Legend
O
Head Attachment Type
Snap-On
Compatible with Series
ZB4
Compatible Operator Illumination
Non-Illuminated
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER ELECTRIC Push Button Head (MPN ZBA7432) is a non-illuminated head for push buttons with a 22 mm panel size and a red color. It features a snap-on head attachment type and is compatible with the ZB4 series. The head is marked with the legend 'O'.

Frequently Asked Questions

What is the SCHNEIDER ELECTRIC Push Button Head ZBA7432 used for?

The SCHNEIDER ELECTRIC Push Button Head ZBA7432 is a non-illuminated red head for 22 mm panel-mount push buttons. It is used in industrial control panels, machinery, and automation systems as a momentary or maintained operator, typically for stop or off functions, and snaps onto ZB4 series contact blocks.

What are the specifications of the SCHNEIDER ZBA7432 push button head?

The SCHNEIDER ZBA7432 is a non-illuminated push button head with a 22 mm panel size, red color, and legend 'O'. It features a snap-on head attachment type and is compatible with the ZB4 series. The manufacturer part number is ZBA7432, and it is designed for use with SCHNEIDER contact blocks and operators.

Where to buy the SCHNEIDER ZBA7432 push button head worldwide?

You can source the SCHNEIDER ZBA7432 push button head worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we provide reliable sourcing for SCHNEIDER components.

How to install the SCHNEIDER ZBA7432 push button head?

To install the SCHNEIDER ZBA7432 push button head, snap it onto a compatible ZB4 series contact block or operator. Ensure the panel cutout is 22 mm. Align the head's mounting collar with the operator and press firmly until it locks. No tools are required for snap-on attachment. Follow standard industrial control panel wiring practices.

Used in

Common applications for SCHNEIDER
Motor starting in conveyor systems — Schneider Altistart ATS 22 soft starters (e.g., ATS22D17S6U) reduce inrush current.
Speed control for industrial pumps — Schneider Altivar ATV320 VFDs (e.g., ATV320U55N4W) provide variable flow regulation.
Machine safety interlocking — Schneider XPSUAF13AP safety relays monitor emergency stop circuits on assembly lines.
Panel-mounted control stations — Schneider XB5 flush push buttons (ZB5AA5) serve as start/stop operators in MCCs.
Heavy-duty motor switching — Schneider LC1G150LSEA contactors handle 150 A loads in compressor and crusher applications.
Emergency stop actuation — Schneider 9001K mushroom-head push buttons (9001KR25R) provide red, momentary stop functions.
