SCHNEIDER Illuminated Push Button: Illuminated, Flush Profile, Non-Metallic, 16 mm - Illuminated Flush-Mount Push Buttons
SCHNEIDERIlluminated Flush-Mount Push Buttons

SCHNEIDER Illuminated Push Button: Illuminated, Flush Profile, Non-Metallic, 16 mm

The SCHNEIDER Illuminated Push Button is an illuminated flush-mount push button from the XB6 series, featuring a maintained action and a non-metallic construction. It includes a 16 mm flush profile with 1NO/1NC…

SKU 3G-OTH-34063

Brand
SCHNEIDER
Item
Illuminated Push Button: Illuminated, Flush Profile, Non-Metallic, 16 mm
Category
Illuminated Flush-Mount Push Buttons
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
XB6DF4B5B
Series
XB6
Type
Flush Profile, Non-Metallic, 16 mm, 1NO/1NC
Action
Maintained
Terminal Connection
Quick Connect
Push Button Material Type
Non-Metallic
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER Illuminated Push Button is an illuminated flush-mount push button from the XB6 series, featuring a maintained action and a non-metallic construction. It includes a 16 mm flush profile with 1NO/1NC contacts and quick-connect terminals (MPN XB6DF4B5B).

Frequently Asked Questions

What is the SCHNEIDER Illuminated Push Button used for?

The SCHNEIDER Illuminated Push Button is used for industrial control panel applications requiring a maintained-action illuminated switch. Its flush, non-metallic 16 mm profile suits environments where corrosion resistance and visual status indication are needed, such as in machinery, conveyors, and process equipment.

What are the specifications of the SCHNEIDER XB6DF4B5B?

The SCHNEIDER XB6DF4B5B is a maintained-action illuminated push button from the XB6 series. It features a flush, non-metallic 16 mm profile with 1NO/1NC contacts and quick-connect terminals. The push button material is non-metallic, making it suitable for applications requiring corrosion resistance.

Where to buy SCHNEIDER XB6DF4B5B worldwide?

You can source the SCHNEIDER XB6DF4B5B illuminated push button through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring the component reaches your facility reliably.

How to install the SCHNEIDER XB6DF4B5B push button?

Install the SCHNEIDER XB6DF4B5B by mounting it into a 16 mm panel cutout. Connect wires to the quick-connect terminals per the 1NO/1NC contact configuration. Ensure the maintained-action mechanism is correctly aligned. Follow standard electrical safety practices and consult the manufacturer's datasheet for torque and wiring details.
