SCHNEIDER Push Button Head: 30 mm Panel Size, Non-Illuminated - Heads for Push Buttons
SCHNEIDERHeads for Push Buttons

SCHNEIDER Push Button Head: 30 mm Panel Size, Non-Illuminated

The SCHNEIDER ELECTRIC Push Button Head (MPN ZB4FA9) is a non-illuminated, metallic head for push buttons, compatible with the XB4 series. It features a 30 mm panel size and a screw-on attachment type, constructed…

SKU 3G-OTH-32610

Brand
SCHNEIDER
Item
Push Button Head: 30 mm Panel Size, Non-Illuminated
Category
Heads for Push Buttons
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
ZB4FA9
Head Material
Metal
Head Attachment Type
Screw-On
Compatible with Series
XB4
Compatible Operator Illumination
Non-Illuminated
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER ELECTRIC Push Button Head (MPN ZB4FA9) is a non-illuminated, metallic head for push buttons, compatible with the XB4 series. It features a 30 mm panel size and a screw-on attachment type, constructed from metal. This head is designed for use as a component in industrial control stations.

Frequently Asked Questions

What is the SCHNEIDER ELECTRIC ZB4FA9 push button head used for?

The SCHNEIDER ELECTRIC ZB4FA9 is a non-illuminated, metallic push button head used as a component in industrial control stations. It mounts on XB4 series operators and is designed for 30 mm panel cutouts, providing durable actuation in manufacturing, process control, and automation environments.

What are the specifications of the SCHNEIDER ZB4FA9 push button head?

The ZB4FA9 is a metal push button head with a 30 mm panel size, screw-on attachment, and non-illuminated operation. It is compatible with the SCHNEIDER XB4 series. The head material is metal, and the manufacturer part number is ZB4FA9. It is not illuminated.

Where to buy the SCHNEIDER ZB4FA9 push button head worldwide?

You can source the SCHNEIDER ZB4FA9 push button head from 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine SCHNEIDER components.

How to install the SCHNEIDER ZB4FA9 push button head?

To install the ZB4FA9, screw the metallic head onto a compatible XB4 series operator body through a 30 mm panel cutout. Ensure the head is tightened securely by hand or with a suitable tool. Follow standard industrial control station wiring and mounting practices for reliable operation.

Used in

Common applications for SCHNEIDER
Motor starting in conveyor systems — Schneider Altistart ATS 22 soft starters (e.g., ATS22D17S6U) reduce inrush current.
Speed control for industrial pumps — Schneider Altivar ATV320 VFDs (e.g., ATV320U55N4W) provide variable flow regulation.
Machine safety interlocking — Schneider XPSUAF13AP safety relays monitor emergency stop circuits on assembly lines.
Panel-mounted control stations — Schneider XB5 flush push buttons (ZB5AA5) serve as start/stop operators in MCCs.
Heavy-duty motor switching — Schneider LC1G150LSEA contactors handle 150 A loads in compressor and crusher applications.
Emergency stop actuation — Schneider 9001K mushroom-head push buttons (9001KR25R) provide red, momentary stop functions.

SCHNEIDER Products

3G Electric supplies SCHNEIDER heads for push buttons. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
