SCHNEIDER Supplementary Protector: 5 A Amps, 250V DC, 5kA at 250V DC, Lug, C60H-DC - DC-Only Rated, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors
SCHNEIDERDC-Only Rated, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors

SCHNEIDER Supplementary Protector: 5 A Amps, 250V DC, 5kA at 250V DC, Lug, C60H-DC

The SCHNEIDER IEC Supplementary Protector is a DC-only rated, 1-pole UL1077 DIN rail-mount supplementary protector with a 5 A amp rating. Part of the C60H-DC series, it features a C curve type, a maximum AIR rating…

SKU 3G-OTH-19596

Brand
SCHNEIDER
Item
Supplementary Protector: 5 A Amps, 250V DC, 5kA at 250V DC, Lug, C60H-DC
Category
DC-Only Rated, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
MGN61505
Series
C60H-DC
Type
5kA at 250V DC, Lug, C60H-DC, C
DC
250V
Curve Type
C
Max. AIR Rating
5kA at 250V DC
AC Voltage Rating
Not Rated
DC Voltage Rating
250V DC
Terminal Connection
Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER IEC Supplementary Protector is a DC-only rated, 1-pole UL1077 DIN rail-mount supplementary protector with a 5 A amp rating. Part of the C60H-DC series, it features a C curve type, a maximum AIR rating of 5kA at 250V DC, and a lug terminal connection (MPN MGN61505). It is rated for 250V DC and is not rated for AC voltage.
