SCHNEIDER Recessed Push Button: 22 mm Mounting Size, Metallic - Flush-Mount & Recessed Push-Button Operators
SCHNEIDERFlush-Mount & Recessed Push-Button Operators

SCHNEIDER Recessed Push Button: 22 mm Mounting Size, Metallic

The SCHNEIDER Recessed Push Button (MPN ZB4BA56) is a flush-mount and recessed push-button operator from the XB4 series. This metallic momentary-action device features a 22 mm mounting size. It is designed for…

SKU 3G-OTH-34452

Brand
SCHNEIDER
Item
Recessed Push Button: 22 mm Mounting Size, Metallic
Category
Flush-Mount & Recessed Push-Button Operators
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
ZB4BA56
Series
XB4
Action
Momentary
Push Button Material Type
Metallic
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER Recessed Push Button (MPN ZB4BA56) is a flush-mount and recessed push-button operator from the XB4 series. This metallic momentary-action device features a 22 mm mounting size. It is designed for industrial control panel applications requiring a durable, flush-mounted operator.

Frequently Asked Questions

What is the SCHNEIDER ZB4BA56 recessed push button used for?

The SCHNEIDER ZB4BA56 is a flush-mount push button used in industrial control panels. Its momentary action and 22 mm mounting size make it suitable for machine start, stop, or signaling applications where a durable, metallic operator is required.

What are the specifications of the SCHNEIDER ZB4BA56?

The SCHNEIDER ZB4BA56 is a metallic, momentary push button from the XB4 series. It has a 22 mm mounting size and is designed for flush-mount installation. The manufacturer part number is ZB4BA56, and the push button material is metallic.

Where to buy the SCHNEIDER ZB4BA56 worldwide?

3G Electric supplies the SCHNEIDER ZB4BA56 worldwide. As a global industrial distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to install the SCHNEIDER ZB4BA56 recessed push button?

Install the SCHNEIDER ZB4BA56 into a 22 mm panel cutout. Secure the operator with the provided mounting nut, then connect the appropriate contact block (sold separately) per the wiring diagram. Ensure the panel is de-energized during installation.
