SCHNEIDER Flush Push Button: 22 mm Mounting Size, Metallic - Flush-Mount & Recessed Push-Button Operators
SCHNEIDERFlush-Mount & Recessed Push-Button Operators

SCHNEIDER Flush Push Button: 22 mm Mounting Size, Metallic

The SCHNEIDER Flush Push Button is a flush-mount and recessed push-button operator from the XB4 series, featuring a metallic construction and a maintained action. It has a 22 mm mounting size and is identified by…

SKU 3G-OTH-35365

Brand
SCHNEIDER
Item
Flush Push Button: 22 mm Mounting Size, Metallic
Category
Flush-Mount & Recessed Push-Button Operators
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
ZB4BH01
Series
XB4
Action
Maintained
Push Button Material Type
Metallic
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER Flush Push Button is a flush-mount and recessed push-button operator from the XB4 series, featuring a metallic construction and a maintained action. It has a 22 mm mounting size and is identified by manufacturer part number ZB4BH01.

Frequently Asked Questions

What is the SCHNEIDER Flush Push Button ZB4BH01 used for?

The SCHNEIDER Flush Push Button ZB4BH01 is a maintained-action operator used in industrial control panels for start/stop or on/off commands. Its flush metallic design suits harsh environments, and the 22 mm mounting size fits standard XB4 enclosures. Common applications include manufacturing lines, conveyors, and machinery control stations.

What are the specifications of the SCHNEIDER ZB4BH01 push button?

The SCHNEIDER ZB4BH01 is a metallic flush push button from the XB4 series. It features a maintained action (latching), a 22 mm mounting diameter, and a metallic push button material. The manufacturer part number is ZB4BH01. It is designed for flush-mount and recessed operator applications in industrial control systems.

Where to buy SCHNEIDER ZB4BH01 push button worldwide?

3G Electric supplies the SCHNEIDER ZB4BH01 flush push button worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time. We source genuine SCHNEIDER XB4 series components for industrial control panel builders and maintenance teams.

How to install the SCHNEIDER ZB4BH01 flush push button?

To install the SCHNEIDER ZB4BH01, mount it into a 22 mm panel cutout and secure it with the provided locking ring. Wire the maintained-action contacts according to your control circuit diagram. Ensure the panel is de-energized during installation. Refer to the XB4 series installation manual for torque specifications and environmental ratings.
