SCHNEIDER Flush Push Button: Red, 22 mm Mounting Size, Non-Metallic - Flush-Mount & Recessed Push-Button Operators
SCHNEIDERFlush-Mount & Recessed Push-Button Operators

SCHNEIDER Flush Push Button: Red, 22 mm Mounting Size, Non-Metallic

The SCHNEIDER Flush Push Button (MPN ZB5AH04) is a flush-mount and recessed push-button operator from the XB5 series. This red, non-metallic unit features a maintained action and a 22 mm mounting size, designed for…

SKU 3G-OTH-33143

Brand
SCHNEIDER
Item
Flush Push Button: Red, 22 mm Mounting Size, Non-Metallic
Category
Flush-Mount & Recessed Push-Button Operators
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
ZB5AH04
Series
XB5
Action
Maintained
Push Button Material Type
Non-Metallic
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER Flush Push Button (MPN ZB5AH04) is a flush-mount and recessed push-button operator from the XB5 series. This red, non-metallic unit features a maintained action and a 22 mm mounting size, designed for industrial control panel applications.

Frequently Asked Questions

What is the SCHNEIDER ZB5AH04 flush push button used for?

The SCHNEIDER ZB5AH04 is a flush push button used in industrial control panels for maintained switching actions. Its red, non-metallic design suits applications requiring a durable, corrosion-resistant operator in manufacturing, processing, and automation environments.

What are the specifications of the SCHNEIDER ZB5AH04 push button?

The SCHNEIDER ZB5AH04 is a maintained-action flush push button from the XB5 series. It features a 22 mm mounting size, a non-metallic red actuator, and is designed for panel-mount installation. The part number is ZB5AH04, and it is manufactured by SCHNEIDER.

Where to buy the SCHNEIDER ZB5AH04 worldwide?

3G Electric supplies the SCHNEIDER ZB5AH04 flush push button worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time on this XB5 series maintained-action operator.

How to install the SCHNEIDER ZB5AH04 flush push button?

To install the SCHNEIDER ZB5AH04, mount it into a 22 mm panel cutout and secure it with the provided locking ring. Wire the maintained-action contacts according to your control circuit diagram. Always follow standard electrical safety practices and consult the XB5 series installation guide.

Used in

Common applications for SCHNEIDER
Motor starting in conveyor systems — Schneider Altistart ATS 22 soft starters (e.g., ATS22D17S6U) reduce inrush current.
Speed control for industrial pumps — Schneider Altivar ATV320 VFDs (e.g., ATV320U55N4W) provide variable flow regulation.
Machine safety interlocking — Schneider XPSUAF13AP safety relays monitor emergency stop circuits on assembly lines.
Panel-mounted control stations — Schneider XB5 flush push buttons (ZB5AA5) serve as start/stop operators in MCCs.
Heavy-duty motor switching — Schneider LC1G150LSEA contactors handle 150 A loads in compressor and crusher applications.
Emergency stop actuation — Schneider 9001K mushroom-head push buttons (9001KR25R) provide red, momentary stop functions.
