SCHNEIDER Lamp Module: 22 mm Size, Clear, Incandescent, 120 V AC Rating - Lamp Modules
SCHNEIDERLamp Modules

SCHNEIDER Lamp Module: 22 mm Size, Clear, Incandescent, 120 V AC Rating

The SCHNEIDER ELECTRIC Lamp Module (SKU 6HW25, MPN ZB5AV3) is a 22 mm size incandescent lamp module with a clear lens and 120 V AC rating. It includes a bulb and is compatible with the XB5 series selector switch…

SKU 3G-OTH-36260

Brand
SCHNEIDER
Item
Lamp Module: 22 mm Size, Clear, Incandescent, 120 V AC Rating
Category
Lamp Modules
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
ZB5AV3
Type
Clear, Incandescent, Transformer
AC Rating
120 V
Includes Bulb
Bulb Included
Compatible Operator
Selector Switch
Compatible with Series
XB5
Terminal Connection Type
Screw Clamp Terminals
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question
