SCHNEIDER Soft Start: 208-600V AC, 62 A Output Current, With Bypass, IP20/NEMA 1 - Schneider Altistart ATS 22
SCHNEIDERSchneider Altistart ATS 22

SCHNEIDER Soft Start: 208-600V AC, 62 A Output Current, With Bypass, IP20/NEMA 1

The SCHNEIDER Soft Start: 208-600V AC is a Schneider Altistart ATS 22 soft starter with model number ATS22D62S6U. It features a 62 A output current, includes bypass, and is rated IP20/NEMA 1 with 60/50 Hz frequency…

SKU 3G-OTH-159635

Brand
SCHNEIDER
Item
Soft Start: 208-600V AC, 62 A Output Current, With Bypass, IP20/NEMA 1
Category
Schneider Altistart ATS 22
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
ATS22D62S6U
Type
With Bypass, IP20/NEMA 1, 60/50 Hz
AC
110V
Output Current
62 A
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER Soft Start: 208-600V AC is a Schneider Altistart ATS 22 soft starter with model number ATS22D62S6U. It features a 62 A output current, includes bypass, and is rated IP20/NEMA 1 with 60/50 Hz frequency and 110V AC control voltage.

Frequently Asked Questions

What is the Schneider Altistart ATS 22 soft starter used for?

The Schneider Altistart ATS 22 soft starter is used to control the acceleration and deceleration of three-phase induction motors, reducing mechanical stress and electrical inrush current. It is commonly applied in pumps, fans, conveyors, and compressors in industrial and commercial facilities.

What are the specifications of the Schneider ATS22D62S6U soft starter?

The Schneider ATS22D62S6U is an Altistart ATS 22 soft starter rated for 208-600V AC input, with a 62 A output current. It includes a bypass contactor, is IP20/NEMA 1 rated, operates at 60/50 Hz, and uses a 110V AC control voltage. The manufacturer part number is ATS22D62S6U.

Where to buy the Schneider ATS22D62S6U soft starter worldwide?

You can source the Schneider ATS22D62S6U soft starter worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to select the correct Schneider Altistart ATS 22 soft starter for a motor?

To select the correct Schneider Altistart ATS 22 soft starter, match the soft starter's output current rating (e.g., 62 A for the ATS22D62S6U) to the motor's full-load current. Also verify the input voltage range (208-600V AC), control voltage (110V AC), and enclosure type (IP20/NEMA 1) meet your application requirements.
