SCHNEIDER Surge Arrester: Two Phase, 120/240V AC, 2 Poles, 3 Wires, L-N - DIN Rail Internal-Mount SPDs
SCHNEIDERDIN Rail Internal-Mount SPDs

SCHNEIDER Surge Arrester: Two Phase, 120/240V AC, 2 Poles, 3 Wires, L-N

The SCHNEIDER ELECTRIC Surge Arrester (MPN M9L12240) is a two-phase DIN Rail internal-mount SPD designed for 120/240V AC systems. It features 3-wire configuration with L-N protection modes, a voltage protection…

SKU 3G-OTH-22551

Brand
SCHNEIDER
Item
Surge Arrester: Two Phase, 120/240V AC, 2 Poles, 3 Wires, L-N
Category
DIN Rail Internal-Mount SPDs
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
M9L12240
Type
L-N, 200 kA
AC
120/240V
Phase
Two
Poles
2
Wires
3
Voltage
120/240V AC
Mounting Style
DIN-Rail
Number of Wires
3 Wires
Modes of Protection
L-N
Voltage Protection Rating
1200V (L-L)
Short Circuit Current Rating
200 kA
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER ELECTRIC Surge Arrester (MPN M9L12240) is a two-phase DIN Rail internal-mount SPD designed for 120/240V AC systems. It features 3-wire configuration with L-N protection modes, a voltage protection rating of 1200V (L-L), and a short circuit current rating of 200 kA.
