SCHNEIDER Joystick Operators: Vertical and Horizontal Operation, 2 Positions
The SCHNEIDER ELECTRIC Joystick Operators: Vertical and Horizontal Operation (SKU 832U49, MPN XDPC5555C4) are joystick operators with contact blocks from the XK series. This unit features a plastic bezel, a momentary…
SKU 3G-OTH-36617
Need installation or engineering help?
Ask a question
Product Description
The SCHNEIDER ELECTRIC Joystick Operators: Vertical and Horizontal Operation (SKU 832U49, MPN XDPC5555C4) are joystick operators with contact blocks from the XK series. This unit features a plastic bezel, a momentary switch action, and a contact form of 4NO/NC with 2 positions plus center off.
Frequently Asked Questions
What is the SCHNEIDER ELECTRIC XDPC5555C4 joystick operator used for?
The SCHNEIDER ELECTRIC XDPC5555C4 joystick operator is used for vertical and horizontal control in industrial machinery, conveyors, and material handling equipment. Its momentary switch action and 4NO/NC contact form make it suitable for precise, temporary commands in control panels and operator stations.
What are the specifications of the SCHNEIDER XDPC5555C4 joystick?
The SCHNEIDER XDPC5555C4 is a joystick operator from the XK series with a plastic bezel, momentary switch action, and 4NO/NC contact form. It offers 2 positions plus center off, providing vertical and horizontal operation. The manufacturer part number is XDPC5555C4, and the SKU is 832U49.
Where to buy SCHNEIDER joystick operators worldwide?
You can source the SCHNEIDER XDPC5555C4 joystick operator through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we provide reliable sourcing for SCHNEIDER XK series components.
How to install the SCHNEIDER XDPC5555C4 joystick operator?
Install the SCHNEIDER XDPC5555C4 by mounting the plastic bezel into a standard panel cutout, securing it with the provided hardware. Wire the 4NO/NC contacts according to your control circuit diagram, ensuring proper voltage and current ratings. Test the momentary action and center-off position before commissioning.
Used in
Common applications for SCHNEIDERSCHNEIDER Products
3G Electric supplies SCHNEIDER joystick operators with contact blocks. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
