SCHNEIDER ELECTRIC Soft Start: 208-600V AC, 210 A Output Current, With Bypass, IP00/NEMA 1 - Schneider Altistart ATS 22
SCHNEIDER ELECTRICSchneider Altistart ATS 22

SCHNEIDER ELECTRIC Soft Start: 208-600V AC, 210 A Output Current, With Bypass, IP00/NEMA 1

The SCHNEIDER ELECTRIC Soft Start is a Schneider Altistart ATS 22, model ATS22C21S6U, designed for 208-600V AC operation with a 210 A output current. It includes bypass functionality and is rated IP00/NEMA 1…

SKU 3G-OTH-159653

Brand
SCHNEIDER ELECTRIC
Item
Soft Start: 208-600V AC, 210 A Output Current, With Bypass, IP00/NEMA 1
Category
Schneider Altistart ATS 22
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER ELECTRIC
Manufacturer Part Number
ATS22C21S6U
Type
With Bypass, IP00/NEMA 1, 60/50 Hz
Output Current
210 A
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER ELECTRIC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER ELECTRIC Soft Start is a Schneider Altistart ATS 22, model ATS22C21S6U, designed for 208-600V AC operation with a 210 A output current. It includes bypass functionality and is rated IP00/NEMA 1, supporting 60/50 Hz frequencies. The control supply voltage is 110V AC.

Frequently Asked Questions

What is the SCHNEIDER ELECTRIC ATS22C21S6U soft start used for?

The SCHNEIDER ELECTRIC ATS22C21S6U is a soft starter used to control the acceleration and deceleration of three-phase induction motors, reducing mechanical stress and electrical surges. It is commonly applied in pumps, fans, conveyors, and compressors in industrial and commercial facilities.

What are the specifications of the SCHNEIDER ELECTRIC ATS22C21S6U soft start?

The SCHNEIDER ELECTRIC ATS22C21S6U is a Schneider Altistart ATS 22 soft starter with a 210 A output current, operating at 208-600V AC and 60/50 Hz. It includes bypass functionality, is rated IP00/NEMA 1, and has a 110V AC control supply voltage. The manufacturer part number is ATS22C21S6U.

Where to buy the SCHNEIDER ELECTRIC ATS22C21S6U soft start worldwide?

You can source the SCHNEIDER ELECTRIC ATS22C21S6U soft start through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this Schneider Altistart ATS 22 model.

How to install the SCHNEIDER ELECTRIC ATS22C21S6U soft start?

Install the SCHNEIDER ELECTRIC ATS22C21S6U soft start by mounting it vertically on a flat surface, ensuring adequate ventilation for the IP00/NEMA 1 enclosure. Connect the motor and supply cables per the wiring diagram in the Schneider Altistart ATS 22 manual, and set the control supply to 110V AC. Always follow local electrical codes.
