Siemens Surge Protection Device: Single Phase, 120/240V AC, 1200V (L-L)/700V (L-G - Enclosed External-Mount SPDs
SiemensEnclosed External-Mount SPDs

Siemens Surge Protection Device: Single Phase, 120/240V AC, 1200V (L-L)/700V (L-G

The SIEMENS Surge Protection Device is a single-phase enclosed external-mount SPD (SKU 19T307, MPN TPS3A12200X02) with a steel enclosure. It operates at 120/240V AC with a max. continuing operating voltage of 150 V…

SKU 3G-OTH-21072

Brand
Siemens
Item
Surge Protection Device: Single Phase, 120/240V AC, 1200V
Category
Enclosed External-Mount SPDs
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Siemens
Manufacturer Part Number
TPS3A12200X02
Type
1200V (L-L)/700V (L-G, L-N, N-G), Steel
AC
120/240V
Voltage
120/240V AC
Includes
Dry Contacts
Enclosure Material
Steel
Voltage Protection Rating
1200V (L-L)
Max. Surge Current per Mode
100kA (L-G
Max. Continuing Operating Voltage
150 V AC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Siemens Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SIEMENS Surge Protection Device is a single-phase enclosed external-mount SPD (SKU 19T307, MPN TPS3A12200X02) with a steel enclosure. It operates at 120/240V AC with a max. continuing operating voltage of 150 V AC, a voltage protection rating of 1200V (L-L), and a max. surge current per mode of 100kA (L-G). It includes dry contacts.

Frequently Asked Questions

What is the SIEMENS TPS3A12200X02 surge protection device used for?

The SIEMENS TPS3A12200X02 is an enclosed external-mount SPD designed to protect single-phase 120/240V AC electrical systems from voltage surges. It is commonly used in commercial and industrial facilities to safeguard sensitive equipment against transient overvoltages, with a max surge current per mode of 100kA (L-G).

What are the specifications of the SIEMENS TPS3A12200X02 surge protector?

The SIEMENS TPS3A12200X02 is a single-phase SPD rated for 120/240V AC with a max continuing operating voltage of 150 V AC. It offers a voltage protection rating of 1200V (L-L) and 700V (L-G, L-N, N-G), a max surge current per mode of 100kA (L-G), and includes dry contacts. The enclosure is steel.

Where to buy the SIEMENS TPS3A12200X02 surge protection device worldwide?

You can source the SIEMENS TPS3A12200X02 surge protection device worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we supply genuine SIEMENS components to any country.

How to install the SIEMENS TPS3A12200X02 external-mount SPD?

Install the SIEMENS TPS3A12200X02 SPD by mounting the steel enclosure securely near the main service panel. Connect the line, neutral, and ground conductors per the wiring diagram, ensuring the max continuing operating voltage of 150 V AC is not exceeded. Use dry contacts for remote monitoring. Always follow local electrical codes and consult a qualified electrician.
