Siemens Molded Case Circuit Breaker: 70 A Amps, 18kA at 480V AC, Fixed, Load Side Lug - ED-Frame Siemens Molded Case Circuit Breakers
SiemensED-Frame Siemens Molded Case Circuit Breakers

Siemens Molded Case Circuit Breaker: 70 A Amps, 18kA at 480V AC, Fixed, Load Side Lug

The SIEMENS Molded Case Circuit Breaker is an ED-Frame, ED4-series device rated for 70 A with a maximum AIR rating of 18kA at 480V AC. It features a fixed instantaneous trip, load-side lug terminal connection, and…

SKU 3G-OTH-22404

Brand
Siemens
Item
Molded Case Circuit Breaker: 70 A Amps, 18kA at 480V AC, Fixed, Load Side Lug
Category
ED-Frame Siemens Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Siemens
Manufacturer Part Number
ED42B070
Series
ED4
Type
18kA at 480V AC, Fixed, Load Side Lug, Any, ED4
Max. AIR Rating
18kA at 480V AC
Phase Connection
Any
Instantaneous Trip
Fixed
Terminal Connection
Load Side Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Siemens Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SIEMENS Molded Case Circuit Breaker is an ED-Frame, ED4-series device rated for 70 A with a maximum AIR rating of 18kA at 480V AC. It features a fixed instantaneous trip, load-side lug terminal connection, and supports any phase connection (MPN ED42B070).

Frequently Asked Questions

What is the SIEMENS ED42B070 molded case circuit breaker used for?

The SIEMENS ED42B070 is an ED-Frame, ED4-series molded case circuit breaker rated for 70 A. It protects electrical circuits from overloads and short circuits in industrial power distribution, motor control centers, and panelboards, with a maximum AIR rating of 18kA at 480V AC.

What are the specifications of the SIEMENS ED42B070 circuit breaker?

The SIEMENS ED42B070 is a 70 A molded case circuit breaker with a maximum AIR rating of 18kA at 480V AC. It features a fixed instantaneous trip, load-side lug terminal connection, supports any phase connection, and is part of the ED4 series (MPN ED42B070).

Where to buy the SIEMENS ED42B070 circuit breaker worldwide?

3G Electric supplies the SIEMENS ED42B070 molded case circuit breaker to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this ED4-series device.

How to select the right SIEMENS molded case circuit breaker for an application?

To select the right SIEMENS molded case circuit breaker, match the continuous current rating (e.g., 70 A for the ED42B070) to your load, verify the available fault current does not exceed the AIR rating (18kA at 480V AC), and confirm terminal type (load-side lug) and phase connection (any) suit your panel.
