Siemens Magnetic Motor Starter: Reversing, 3 Poles, NEMA Size 00, 9 A - Reversing Starters with Electronic Overloads
SiemensReversing Starters with Electronic Overloads

Siemens Magnetic Motor Starter: Reversing, 3 Poles, NEMA Size 00, 9 A

The SIEMENS NEMA Magnetic Motor Starter is a reversing starter with electronic overloads, featuring three poles and NEMA Size 00. It operates with a 110/120V AC coil voltage, includes a pilot light and one normally…

SKU 3G-OTH-43284

Brand
Siemens
Item
Magnetic Motor Starter: Reversing, 3 Poles, NEMA Size 00, 9 A
Category
Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Siemens
Manufacturer Part Number
22BUC32AF
Type
NEMA Size 00, 9 A
Phase
Three
Poles
3
AC Coil
120V
Coil Voltage
110/120V AC
Signaling Features
Pilot Light
Auxiliary Contact Form
1NO
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Terminal Connection Type
Screw Terminals
Auxiliary Contacts Included
1NO
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Siemens Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SIEMENS NEMA Magnetic Motor Starter is a reversing starter with electronic overloads, featuring three poles and NEMA Size 00. It operates with a 110/120V AC coil voltage, includes a pilot light and one normally open auxiliary contact, and uses screw terminals. No thermal units are required as the overload protection is electronic.

Frequently Asked Questions

What is the SIEMENS 22BUC32AF reversing motor starter used for?

The SIEMENS 22BUC32AF is a NEMA Size 00 reversing magnetic motor starter used to control the forward and reverse rotation of three-phase AC motors in industrial applications such as conveyors, hoists, and pumps. It includes an electronic overload relay and a pilot light for status indication.

What are the specifications of the SIEMENS 22BUC32AF reversing starter?

The SIEMENS 22BUC32AF is a three-pole, NEMA Size 00 reversing starter rated for 9 A at 120V AC coil voltage. It features screw terminals, one normally open auxiliary contact, and an electronic overload that eliminates the need for thermal units. It operates on three-phase power.

Where to buy the SIEMENS 22BUC32AF reversing motor starter worldwide?

3G Electric supplies the SIEMENS 22BUC32AF reversing motor starter to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this NEMA Size 00 starter.

How to select the correct overload protection for the SIEMENS 22BUC32AF starter?

The SIEMENS 22BUC32AF uses an electronic overload relay, so no separate thermal units are required. To select the correct overload setting, match the motor full-load amperage to the adjustable range of the electronic overload module. Consult the motor nameplate and SIEMENS documentation for precise adjustment.
