Siemens Magnetic Motor Starter: Reversing, 3 Poles, NEMA Size 1, 27 A - Reversing Starters with Electronic Overloads
SiemensReversing Starters with Electronic Overloads

Siemens Magnetic Motor Starter: Reversing, 3 Poles, NEMA Size 1, 27 A

The SIEMENS NEMA Magnetic Motor Starter: Reversing (SKU 44N859, MPN 22DUB32AF) is a three-phase reversing starter with electronic overloads, featuring a 110/120V AC coil, NEMA Size 1, and a 27 A rating. It includes…

SKU 3G-OTH-41633

Brand
Siemens
Item
Magnetic Motor Starter: Reversing, 3 Poles, NEMA Size 1, 27 A
Category
Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Siemens
Manufacturer Part Number
22DUB32AF
Type
NEMA Size 1, 27 A
Phase
Three
Poles
3
AC Coil
120V
Coil Voltage
110/120V AC
Signaling Features
Pilot Light
Auxiliary Contact Form
1NO
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Terminal Connection Type
Screw Terminals
Auxiliary Contacts Included
1NO
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Siemens Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SIEMENS NEMA Magnetic Motor Starter: Reversing (SKU 44N859, MPN 22DUB32AF) is a three-phase reversing starter with electronic overloads, featuring a 110/120V AC coil, NEMA Size 1, and a 27 A rating. It includes screw terminals, one normally open auxiliary contact, and a pilot light for signaling. Thermal units are not required as the overload protection is electronic.

Frequently Asked Questions

What is the SIEMENS NEMA Magnetic Motor Starter 22DUB32AF used for?

This reversing starter controls three-phase motors in industrial applications requiring forward and reverse operation, such as conveyors, hoists, and pumps. It includes electronic overload protection and a pilot light for status signaling.

What are the specifications of the SIEMENS 22DUB32AF motor starter?

The SIEMENS 22DUB32AF is a NEMA Size 1 reversing starter rated 27 A with a 110/120V AC coil. It has three poles, screw terminals, one normally open auxiliary contact, and electronic overloads (no thermal units needed). A pilot light is included for signaling.

Where to buy the SIEMENS 22DUB32AF motor starter worldwide?

3G Electric supplies the SIEMENS 22DUB32AF reversing starter worldwide. As a global industrial distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time.

How to select the correct overload protection for the SIEMENS 22DUB32AF?

The SIEMENS 22DUB32AF uses electronic overloads, so no separate thermal units are required. Set the overload relay dial to match the motor's full-load amperage per the nameplate. Always follow NEC guidelines and the manufacturer's wiring diagram for proper installation.
