Siemens Magnetic Motor Starter: Reversing, 3 Poles, NEMA Size 1, 27 A - Reversing Starters with Electronic Overloads
SiemensReversing Starters with Electronic Overloads

Siemens Magnetic Motor Starter: Reversing, 3 Poles, NEMA Size 1, 27 A

The SIEMENS NEMA Magnetic Motor Starter is a reversing starter with electronic overloads, featuring three poles, NEMA Size 1, and a 27 A rating. It operates on a three-phase supply with a coil voltage of…

SKU 3G-OTH-42812

Brand
Siemens
Item
Magnetic Motor Starter: Reversing, 3 Poles, NEMA Size 1, 27 A
Category
Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Siemens
Manufacturer Part Number
22DUE32AG
Type
NEMA Size 1, 27 A
Phase
Three
Poles
3
AC Coil
240V
Coil Voltage
190-220/220-240V AC
Signaling Features
Pilot Light
Auxiliary Contact Form
1NO
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Terminal Connection Type
Screw Terminals
Auxiliary Contacts Included
1NO
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Siemens Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SIEMENS NEMA Magnetic Motor Starter is a reversing starter with electronic overloads, featuring three poles, NEMA Size 1, and a 27 A rating. It operates on a three-phase supply with a coil voltage of 190-220/220-240V AC and includes a pilot light and 1NO auxiliary contact. Terminal connections are screw type, and no thermal units are required due to the electronic overload design.

Frequently Asked Questions

What is the SIEMENS 22DUE32AG reversing motor starter used for?

The SIEMENS 22DUE32AG reversing magnetic motor starter controls the forward and reverse rotation of three-phase AC motors in industrial applications such as conveyors, hoists, and pumps. It includes an electronic overload relay and a pilot light for status indication.

What are the specifications of the SIEMENS 22DUE32AG motor starter?

This SIEMENS reversing starter is NEMA Size 1, rated 27 A, with three poles and a coil voltage of 190-220/220-240V AC. It includes one normally open auxiliary contact, screw terminals, and an electronic overload that eliminates the need for separate thermal units.

Where to buy the SIEMENS 22DUE32AG reversing starter worldwide?

3G Electric supplies the SIEMENS 22DUE32AG reversing motor starter to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact our team for a quote and lead time on this NEMA Size 1, 27 A unit.

How to select the correct coil voltage for a SIEMENS reversing starter?

Match the coil voltage of the SIEMENS reversing starter to your control circuit supply. The 22DUE32AG accepts 190-220/220-240V AC. Verify your line voltage and phase (three-phase) before ordering. For other voltages, consult 3G Electric for compatible SIEMENS models.
