Siemens Molded Case Circuit Breaker: 150 A Amps, 22kA at 600V AC, Fixed, Lug, ABC - FD-Frame Siemens Molded Case Circuit Breakers
SiemensFD-Frame Siemens Molded Case Circuit Breakers

Siemens Molded Case Circuit Breaker: 150 A Amps, 22kA at 600V AC, Fixed, Lug, ABC

The SIEMENS Molded Case Circuit Breaker (SKU 6FNE2) is an FD-Frame molded case circuit breaker from the FXD6-A series, rated for 150 A amps. It features a fixed instantaneous trip, lug terminal connections, and ABC…

SKU 3G-OTH-20764

Brand
Siemens
Item
Molded Case Circuit Breaker: 150 A Amps, 22kA at 600V AC, Fixed, Lug, ABC
Category
FD-Frame Siemens Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Siemens
Manufacturer Part Number
FXD62B150
Series
FXD6-A
Type
22kA at 600V AC, Fixed, Lug, ABC, FXD6-A
AC
600V
Max. AIR Rating
22kA at 600V AC
Phase Connection
ABC
Instantaneous Trip
Fixed
Terminal Connection
Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Siemens Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SIEMENS Molded Case Circuit Breaker (SKU 6FNE2) is an FD-Frame molded case circuit breaker from the FXD6-A series, rated for 150 A amps. It features a fixed instantaneous trip, lug terminal connections, and ABC phase connection, with a maximum AIR rating of 22kA at 600V AC (MPN FXD62B150).

Frequently Asked Questions

What is the SIEMENS FXD62B150 molded case circuit breaker used for?

The SIEMENS FXD62B150 is an FD-Frame molded case circuit breaker used for overcurrent protection in industrial and commercial electrical distribution systems. It is rated for 150 A amps with a 22kA interrupting rating at 600V AC, making it suitable for branch circuit protection in panelboards and switchboards.

What are the specifications of the SIEMENS FXD62B150 circuit breaker?

The SIEMENS FXD62B150 is an FD-Frame molded case circuit breaker from the FXD6-A series, rated 150 A amps with a max AIR rating of 22kA at 600V AC. It features a fixed instantaneous trip, lug terminal connections, and ABC phase connection. The manufacturer part number is FXD62B150.

Where to buy the SIEMENS FXD62B150 circuit breaker worldwide?

You can source the SIEMENS FXD62B150 circuit breaker through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this Siemens molded case circuit breaker.

How to select the correct SIEMENS molded case circuit breaker for your application?

To select the correct Siemens molded case circuit breaker, verify the continuous current rating (150 A for the FXD62B150), interrupting capacity (22kA at 600V AC), phase connection (ABC), and terminal type (lug). Ensure the frame size (FD-Frame) matches your panelboard or switchboard requirements. Consult a licensed electrician for proper coordination.
