SMC Fitting: 1/2 in OD x 1/2 in OD Size, Compression x Compression - PFA Compression Tube Fittings
SMCPFA Compression Tube Fittings

SMC Fitting: 1/2 in OD x 1/2 in OD Size, Compression x Compression

The SMC LQ3U4A5A-S is a PFA compression tube fitting with 1/2 in OD x 1/2 in OD size and compression x compression type. It meets RoHS_6 and RoHS_10 standards, part of the LQ3 series from SMC.

SKU 3G-OTH-474366

Brand
SMC
Item
Fitting: 1/2 in OD x 1/2 in OD Size, Compression x Compression
Category
PFA Compression Tube Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SMC
Manufacturer Part Number
LQ3U4A5A-S
Series
LQ3
Type
Compression x Compression, PFA
Standards
RoHS_6, RoHS_10
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SMC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SMC LQ3U4A5A-S is a PFA compression tube fitting with 1/2 in OD x 1/2 in OD size and compression x compression type. It meets RoHS_6 and RoHS_10 standards, part of the LQ3 series from SMC.

Frequently Asked Questions

What is the SMC LQ3U4A5A-S PFA compression tube fitting used for?

The SMC LQ3U4A5A-S is a PFA compression tube fitting used to connect 1/2 in OD tubing in high-purity fluid systems. It is common in semiconductor, chemical processing, and pharmaceutical applications where chemical resistance and cleanliness are critical.

What are the specifications of the SMC LQ3U4A5A-S fitting?

The SMC LQ3U4A5A-S is a compression x compression PFA fitting with 1/2 in OD x 1/2 in OD size. It is part of the LQ3 series and complies with RoHS_6 and RoHS_10 standards. The manufacturer part number is LQ3U4A5A-S.

Where to buy the SMC LQ3U4A5A-S fitting worldwide?

3G Electric supplies the SMC LQ3U4A5A-S PFA compression tube fitting worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to install the SMC LQ3U4A5A-S PFA compression fitting?

To install the SMC LQ3U4A5A-S, cut the PFA tubing square, deburr the end, and insert it fully into the fitting. Tighten the compression nut by hand, then use a wrench for an additional 1/4 to 1/2 turn. Avoid overtightening to prevent damage.
