SMC Chemical Liquid Valve: 1/4 in, PFA, Compression x Compression, 0.5 MPa Max Pressure (CWP) - Standard High-Purity Manual Diaphragm Valves
SMCStandard High-Purity Manual Diaphragm Valves

SMC Chemical Liquid Valve: 1/4 in, PFA, Compression x Compression, 0.5 MPa Max Pressure (CWP)

The SMC Chemical Liquid Valve (SKU 2AC533) is a standard high-purity manual diaphragm valve with a 1/4 in PFA body and compression x compression connections. It features a PTFE diaphragm, is rated for a maximum…

SKU 3G-OTH-442400

Brand
SMC
Item
Chemical Liquid Valve: 1/4 in, PFA, Compression x Compression, 0.5 MPa Max Pressure
Category
Standard High-Purity Manual Diaphragm Valves
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SMC
Manufacturer Part Number
LVQH20-Z07-1
Type
PFA, Compression x Compression, PTFE
Standards
CSA Certified
Diaphragm Material
PTFE
MPa Max Pressure (CWP)
0.5
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SMC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SMC Chemical Liquid Valve (SKU 2AC533) is a standard high-purity manual diaphragm valve with a 1/4 in PFA body and compression x compression connections. It features a PTFE diaphragm, is rated for a maximum pressure of 0.5 MPa (CWP), and is CSA Certified.

Frequently Asked Questions

What is the SMC Chemical Liquid Valve used for?

The SMC Chemical Liquid Valve is used for precise flow control of high-purity chemicals in semiconductor, pharmaceutical, and industrial processing. Its PFA body and PTFE diaphragm resist corrosion, making it suitable for aggressive fluids where contamination must be avoided.

What are the specifications of the SMC Chemical Liquid Valve?

The SMC Chemical Liquid Valve (MPN LVQH20-Z07-1) has a 1/4 in PFA body with compression x compression connections. It features a PTFE diaphragm, a maximum pressure rating of 0.5 MPa (CWP), and is CSA Certified. It is a standard high-purity manual diaphragm valve.

Where to buy the SMC Chemical Liquid Valve worldwide?

You can source the SMC Chemical Liquid Valve through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this CSA Certified valve.

How to install the SMC Chemical Liquid Valve?

Install the SMC Chemical Liquid Valve by ensuring the PFA compression fittings are clean and properly aligned. Tighten connections to the manufacturer's recommended torque to avoid leaks. Use PTFE-compatible sealants and avoid overtightening, as PFA can deform. Always follow SMC's installation guidelines for high-purity systems.
