SMC Push-Fit Adapter Fitting: 1/8 in OD x 5 mm Pipe Size, Push-to-Connect x Metric - Polybutylene & Brass Tube Fittings
SMCPolybutylene & Brass Tube Fittings

SMC Push-Fit Adapter Fitting: 1/8 in OD x 5 mm Pipe Size, Push-to-Connect x Metric

The SMC Push-Fit Adapter Fitting (MPN KQ2H01-M5A) is a push-to-connect x metric, brass tube fitting for 1/8 in OD x 5 mm pipe sizes. It features a Thread Size A of M5x.08 and is constructed of brass. 3G Electric…

SKU 3G-OTH-489288

Brand
SMC
Item
Push-Fit Adapter Fitting: 1/8 in OD x 5 mm Pipe Size, Push-to-Connect x Metric
Category
Polybutylene & Brass Tube Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SMC
Manufacturer Part Number
KQ2H01-M5A
Type
Push-to-Connect x Metric, Brass, Brass
Thread Size A
M5x.08
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SMC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SMC Push-Fit Adapter Fitting (MPN KQ2H01-M5A) is a push-to-connect x metric, brass tube fitting for 1/8 in OD x 5 mm pipe sizes. It features a Thread Size A of M5x.08 and is constructed of brass. 3G Electric interprets customer demand and delivers this genuine industrial fitting across 14 departments, with specialist depth in combustion, pumps and controls as an authorised distributor.

Frequently Asked Questions

What is the SMC KQ2H01-M5A push-fit adapter fitting used for?

The SMC KQ2H01-M5A is a brass push-to-connect adapter fitting used to join 1/8 in OD tubing to a metric M5x.08 threaded port. It is common in pneumatic systems, instrumentation, and fluid-handling applications across industrial automation and process control.

What are the specifications of the SMC KQ2H01-M5A fitting?

The SMC KQ2H01-M5A is a push-to-connect x metric brass adapter fitting. It accepts 1/8 in OD tubing and has a Thread Size A of M5x.08. The body is brass, and the manufacturer part number is KQ2H01-M5A. It is designed for reliable, leak-free connections in pneumatic circuits.

Where to buy the SMC KQ2H01-M5A fitting worldwide?

3G Electric supplies the genuine SMC KQ2H01-M5A push-fit adapter fitting worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us to source this fitting for your pneumatic or fluid-handling needs.

How to install the SMC KQ2H01-M5A push-to-connect fitting?

To install the SMC KQ2H01-M5A, ensure the tubing is cut square and free of burrs. Push the tube firmly into the fitting until it stops. Pull back gently to confirm it is locked. For the threaded end, apply thread sealant and tighten to the M5x.08 port. Do not overtighten.

Used in

Common applications for SMC
Automotive assembly — SMC ZP3 flat vacuum pads for handling small components in pick-and-place robots
Semiconductor manufacturing — SMC ZM series vacuum generators with needle valves for precise wafer handling
Food packaging — SMC AW-D series filter regulators for clean compressed air in pneumatic actuators
General industrial automation — SMC AS2211F speed control valves for regulating cylinder speeds in conveyor systems
Vacuum conveying — SMC ZH series box-type vacuum generators for material transport in packaging lines
Machine tool coolant systems — SMC ZF series in-line filters to protect vacuum ejectors from debris
