SMC Rotary Actuator: Single Vane Actuator, 180° Rotation Angle, 75 N-m Output Torque - Vane-Style Rotary Actuators
SMCVane-Style Rotary Actuators

SMC Rotary Actuator: Single Vane Actuator, 180° Rotation Angle, 75 N-m Output Torque

The SMC Rotary Actuator is a single vane actuator (MPN CDRB1BW100-180S) offering a 180° rotation angle and 75 N-m output torque with a 65 mm shaft length. It features a magnetic piston, basic design, metric…

SKU 3G-OTH-161109

Brand
SMC
Item
Rotary Actuator: Single Vane Actuator, 180° Rotation Angle, 75 N-m Output Torque
Category
Vane-Style Rotary Actuators
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SMC
Manufacturer Part Number
CDRB1BW100-180S
Shaft Lg
65 mm
Rotation Angle
180°
N-m Output Torque
75
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SMC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SMC Rotary Actuator is a single vane actuator (MPN CDRB1BW100-180S) offering a 180° rotation angle and 75 N-m output torque with a 65 mm shaft length. It features a magnetic piston, basic design, metric dimensions, and side ported configuration.
