SMC Regulator: Die-Cast Zinc, 1/4 in NPT, 7.251887 psi to 123.2821 psi, 1 MPa Max Op Pressure - SMC FRL Air Regulators
SMCSMC FRL Air Regulators

SMC Regulator: Die-Cast Zinc, 1/4 in NPT, 7.251887 psi to 123.2821 psi, 1 MPa Max Op Pressure

The SMC Regulator: Die-Cast Zinc (SKU 807FN9, MPN AR20K-N02-Z-D) is an SMC FRL Air Regulator from the AR-D series. It features a 1/4 in NPT port size, an operating pressure range of 7.251887 psi to 123.2821 psi, and…

SKU 3G-OTH-147544

Brand
SMC
Item
Regulator: Die-Cast Zinc, 1/4 in NPT, 7.251887 psi to 123.2821 psi, 1 MPa Max Op Pressure
Category
SMC FRL Air Regulators
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SMC
Manufacturer Part Number
AR20K-N02-Z-D
Type
7.251887 psi to 123.2821 psi, Knob
NPT
1/4 in
MPa Max Op Pressure
1
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SMC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SMC Regulator: Die-Cast Zinc (SKU 807FN9, MPN AR20K-N02-Z-D) is an SMC FRL Air Regulator from the AR-D series. It features a 1/4 in NPT port size, an operating pressure range of 7.251887 psi to 123.2821 psi, and a maximum operating pressure of 1 MPa, with a knob adjustment.

Frequently Asked Questions

What is the SMC Regulator AR20K-N02-Z-D used for?

The SMC Regulator AR20K-N02-Z-D is used to control and stabilize air pressure in pneumatic systems. It is commonly applied in industrial automation, packaging, and manufacturing lines where precise pressure regulation is required to protect downstream equipment and ensure consistent operation.

What are the specifications of the SMC Regulator AR20K-N02-Z-D?

The SMC Regulator AR20K-N02-Z-D has a 1/4 in NPT port size, an operating pressure range of 7.251887 psi to 123.2821 psi, and a maximum operating pressure of 1 MPa. It features a die-cast zinc body with knob adjustment and is part of the SMC AR-D series.

Where to buy the SMC Regulator AR20K-N02-Z-D worldwide?

You can source the SMC Regulator AR20K-N02-Z-D through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to install the SMC Regulator AR20K-N02-Z-D?

Install the SMC Regulator AR20K-N02-Z-D by connecting the 1/4 in NPT ports to your pneumatic line using appropriate thread sealant. Mount the regulator in a vertical or horizontal position with the knob accessible. Adjust pressure by turning the knob while monitoring a downstream gauge. Always follow SMC installation guidelines.
