SMC Air Cylinder Clevis Pin: CDP-7A

The SMC Air Cylinder Clevis Pin CDP-7A is a clevis mounting hardware component used to attach a clevis bracket to the rod end of an SMC pneumatic cylinder. It enables pivoting motion in automated machinery, packaging lines, and material handling systems where linear actuation requires a flexible joint.

The SMC CDP-7A is a clevis pin with manufacturer part number CDP-7A. It is designed by SMC as a clevis mounting hardware component for use with SMC air cylinders. The pin provides a secure pivot point for cylinder rod-end attachments in pneumatic systems.

You can source the SMC CDP-7A clevis pin through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we source and deliver genuine SMC mounting hardware to your location.

To install the SMC CDP-7A clevis pin, align the clevis bracket with the rod-end hole of the SMC air cylinder. Insert the pin through both components and secure it with the provided retaining ring or cotter pin. Ensure the pin moves freely without binding. Follow SMC's generic mounting guidelines for proper torque and alignment.
