SNAP-TITEH Series Hydraulic Quick-Connect Coupling Plugs

SNAP-TITE Hydraulic Quick Connect Hose Coupling: 1 in, 316 Stainless Steel

SKU 3G-OTH-456976

Brand

SNAP-TITE

Item

Hydraulic Quick Connect Hose Coupling: 1 in, 316 Stainless Steel

Technical Specifications

SNAP-TITE

Manufacturer Part Number

SVHN16-16F

Type

132.5 lpm Max. Flow Rate

Thread Size

1"-11-1/2

Seal Material

Nitrile

Stainless Steel

316

View Full Spec Sheet

Technical Documents

No technical documents available for this product.

Request documentation →

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

SNAP-TITE Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SNAP-TITE H Series Hydraulic Quick-Connect Coupling Plug (MPN SVHN16-16F) is a 1"-11-1/2 thread, 316 stainless steel coupling with a 132.5 lpm max. flow rate and nitrile seal. 3G Electric interprets this demand, sources the genuine OEM part, and supports your application with specialist expertise across 14 industrial departments — including deep knowledge in pumps and controls as an authorised distributor.

Frequently Asked Questions

What is the SNAP-TITE SVHN16-16F hydraulic quick connect coupling used for?

The SNAP-TITE SVHN16-16F is a 1"-11-1/2 thread, 316 stainless steel quick-connect coupling plug used in hydraulic systems for rapid line connection and disconnection under pressure. It is common in mobile equipment, oil and gas, and industrial fluid power applications requiring corrosion resistance and a 132.5 lpm flow rate.

What are the specifications of the SNAP-TITE H Series coupling plug?

The SNAP-TITE H Series plug (MPN SVHN16-16F) has a 1"-11-1/2 thread size, 316 stainless steel body, nitrile seal, and a maximum flow rate of 132.5 lpm. It is designed for hydraulic quick-connect systems and is supplied by 3G Electric as a genuine OEM part.

Where to buy SNAP-TITE hydraulic couplings worldwide?

3G Electric supplies the SNAP-TITE SVHN16-16F hydraulic coupling worldwide. We handle full logistics, customs clearance, and delivery to your site. As a global industrial solutions provider, we source genuine OEM parts and support your application with specialist expertise across 14 industrial departments.

How to select the right SNAP-TITE quick connect coupling?

To select the correct SNAP-TITE coupling, match thread size (1"-11-1/2), material (316 stainless steel for corrosion resistance), seal material (nitrile for petroleum fluids), and flow rate (132.5 lpm max). Confirm the coupling series (H Series) and ensure compatibility with your hydraulic system pressure and fluid type.

Used in

Common applications for SNAP-TITE

Hydraulic tool maintenance — SNAP-TITE IH Series couplings (e.g., VIHC6-6F) for quick hose connections in hydraulic wrenches and crimpers.

Agricultural equipment — SNAP-TITE IH Series couplings (e.g., VIHC4-4M) for hydraulic lines on tractors and harvesters.

Construction machinery — SNAP-TITE IH Series couplings (e.g., VIHC8-8F) for hydraulic circuits on excavators and loaders.

Industrial fluid power systems — SNAP-TITE IH Series couplings (e.g., VIHC12-12F) for connecting hydraulic power units to actuators.

Mobile hydraulic systems — SNAP-TITE IH Series couplings (e.g., VIHC6-6M) for quick disconnects on forklifts and aerial lifts.
